Terminals Wire Range
Z1, Z1 RET through Z8
14 – 22 AWG
TRBL
14 – 22 AWG
SUPV.
14 – 22 AWG
FIRE
14 – 22 AWG
Dialer
14 – 20 AWG
Battery and Line Connections
Designation Terminal Wire Range Description
Battery
Connection
+ Red lead Positive connection for the Standby-batteries
- Black lead Negative connection for the Standby-batteries
AC Power
L 14 AWG Line connection
N 14 AWG Neutral connection
E 14 AWG Ground Connection
Battery leads are provided in the cabinet for recharging the standby-batteries. One end of the battery leads
are permanently connected to the power supply of the Sigma A-CP Fire Control Panel. The opposite end of
the battery leads connect to terminals of the standby-batteries.
Field Terminal Capacity
Field terminal capacity: 14 to 22 AWG solid or stranded wire.
Kentec does not recommend use of wire size smaller than 18 AWG.
