Kentec Electronics Sigma A-CP - Functions and Codes

Functions and Codes
Functions and codes for operating the Sigma A-CP Fire Control Panel in Access Level 2 are described
below:
Function Terminal Codes Description
Test Zones
Z1 t1 Select codes t1 through t8 to place Zones 1 through 8
in Test Mode. Zones in Test Mode automatically reset
3 seconds after operating. The Test Mode On and
Zone Trouble/On Test/Disabled indicators illuminate
when zones 1 through 8 are in Test Mode.
Z2 t2
Z3 t3
Z4 t4
Z5 t5
Z6 t6
Z7 t7
Z8 t8
Disable Zones
Z1 d1 Select codes d1 through d8 to disable Zones 1
through 8. Disabling Zones does not provide fire or
trouble indications on the fire control panel. The
Disablement and Zone Trouble/On Test/Disabled
indicators illuminate when zones 1 through 8 are
disabled.
Z2 d2
Z3 d3
Z4 d4
Z5 d5
Z6 d6
Z7 d7
Z8 d8
