Kenwood eXcelon KDC-X492 - Audio Setup Options; Speaker Setting Configuration

English
|
7
Audio Setup
You can set Sound system , such as follows;
Adjustment Item Display Range
Front High Pass Filter* “HPF” Through/40*/60*/80/100/120/
150/180/220* Hz
Rear High Pass Filter* “HPR” Through/40*/60*/80/100/120/
150/180/220* Hz
Low Pass Filter “LPF SW” 50*/60*/80/100*/120/160*/
Through Hz
Subwoofer Phase* “PHASE” Reverse (180°)/ Normal (0°)
Volume offset “V-OFFSET” –8 — ±0 (AUX: -8— +8)
Loudness* “LOUDNESS” OFF/ON
Dual Zone System* “2ZONE” OFF/ON
*Function of KDC-X492/KDC-MP438U/KDC-MP408U.
*KDC-X492 only. *KDC-MP438U/KDC-MP408U only.
*KDC-MP338 only.
⁄
• Volume offset: Sets each source’s volume as a difference
from the basic volume.
• Loudness: Compensates for low and high tones during
low volume. (Only the low tone is compensated for
when the tuner is selected as a source.)
• Dual Zone System
Main source and sub source (Auxiliary input) output
Front channel and Rear channel separately.
- Set up the channel of sub source by “ZONE2” of <Menu
System> (page 12).
- Select Main source by [SRC] button.
- Adjust the volume of Front channel by Control knob.
- Adjust the volume of Rear channel by <Audio Control>
(page 6) or [5]/[∞] button on the remote control
(page 15).
- The Audio Control has no effect on sub source.
1 Select the source to adjust
Press the [SRC] button.
2 Enter Audio Setup mode
Press the Control knob for at least 1 second.
3 Select the Audio Setup item to adjust
Press the Control knob.
4 Adjust the Audio setup item
Turn the Control knob.
5 Exit Audio Setup mode
Press the Control knob for at least 1 second.
Speaker Setting
Fine-tuning so that the System Q value is optimal
when setting the speaker type as follows;
Speaker type Display
OFF “SP SEL OFF”
For 5 & 4 in. speaker “SP SEL 5/4”
For 6 & 6x9 in. speaker “SP SEL 6*9/6”
For the OEM speaker “SP SEL OEM”
1 Enter Standby
Press the [SRC] button.
Select the “STANDBY” display.
2 Enter Speaker Setting mode
Press the Control knob.
3 Select the Speaker type
Turn the Control knob.
4 Exit Speaker Setting mode
Press the Control knob.
