Kenwood KAC-6203 User Manual

4 English
Controls / Indicator
(W)
30
40
20
10
1 2
2
1 FILTER switch
This switch allow filtering of the speaker output
signals.
• OFF position:
The original sound without filtering is output.
• LPF (Low-Pass Filter) position:
Only frequencies of 80 Hz or lower are output.
(Frequencies above 80 Hz are cut.)
The speaker output is automatically turned
monaural (L+R) and the bass boost function is
activated.
2 INPUT SENSITIVITY control
Set this control according to the pre-output level
of the center unit connected with this unit, or
to the maximum power output of the genuine-
accessory car stereo.
Use the diagram on the right as a guide.
NOTE
For the pre-output level or the maximum power
output, refer to the <Specifications> in the
instruction manual of the center unit.
3 Power indicator
When the power is turned on, the Power indicator
lights.
If the Power indicator does not light when the
power is turned on, the protection function may
be activated. Check whether there is any indication
of trouble.
B64-3355-0000E.indb4B64-3355-0000E.indb4 05.11.1710:15:43AM05.11.1710:15:43AM
130.com.ua
Autogood products internet store http://130.com.ua

Kenwood KAC-6203 Specifications

General

Impedance	10000 Ω
Frequency range	10 - 50000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Output power	600 W
Product color	Black

Weight and Dimensions

Depth	230 mm
Height	60 mm
Weight	2700 g
