ENGLISH
43
Audio
Maximum Output Power 50 W × 4
Full Bandwidth Power
(at less than 1 % THD)
22 W × 4
Speaker Impedance 4 Ω — 8 Ω
Tone Action Band 1: 62.5 Hz ±9 dB
Band 2: 100 Hz ±9 dB
Band 3: 160 Hz ±9 dB
Band 4: 250 Hz ±9 dB
Band 5: 400 Hz ±9 dB
Band 6: 630 Hz ±9 dB
Band 7: 1 kHz ±9 dB
Band 8: 1.6 kHz ±9 dB
Band 9: 2.5 kHz ±9 dB
Band 10: 4 kHz ±9 dB
Band 11: 6.3 kHz ±9 dB
Band 12: 10 kHz ±9 dB
Band 13: 16 kHz ±9 dB
Preout Level/Load (CD)
:
5 000 mV/10 kΩ load
:
4 000 mV/10 kΩ load
/ /
/ / /
:
2 500 mV/10 kΩ load
Preout Impedance ≤ 600 Ω
SPECIFICATIONS
General
Operating Voltage 12 V DC car battery
Installation Size (W × H × D) 182 mm × 53 mm × 155.5 mm
(7-3/16" × 2-1/16" × 6-1/8")
Net Weight (includes Trimplate,
Mounting Sleeve)
1.2 kg (2.7 lbs)
Subject to change without notice.
