Kenwood KDC-BT510U User Manual

ENGLISH
29
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
INSTALLATION/CONNECTION
Warning
• The unit can only be used with a 12V DC power supply, negative ground.
• Disconnect the battery’s negative terminal before wiring and mounting.
• Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire
(black) to prevent a short circuit.
• Insulate unconnected wires with vinyl tape to prevent a short circuit.
• Be sure to ground this unit to the car’s chassis again after installation.
Caution
• For safety’s sake, leave wiring and mounting to professionals. Consult the car audio dealer.
• Install this unit in the console of your vehicle. Do not touch the metal parts of this unit during
and shortly after use of the unit. Metal parts such as the heat sink and enclosure become hot.
• Do not connect the [ wires of speakers to the car chassis or Ground wire (black), or connect
them in parallel.
• Mount the unit at an angle of less than 30º.
• If your vehicle wiring harness does not have the ignition terminal, connect Ignition wire (red)
to the terminal on the vehicle’s fuse box which provides 12 V DC power supply and is turned
on and off by the ignition key.
• Keep all cables away from heat dissipate metal parts.
• After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are
working properly.
• If the fuse blows, first make sure the wires are not touching car’s chassis, then replace the old
fuse with one that has the same rating.
Basic procedure
1 Remove the key from the ignition switch, then disconnect the [ terminal of the car
battery.
2 Connect the wires properly.
See Wiring connection.
( 31)
3 Install the unit to your car.
See Installing the unit (in-dash mounting).
( 30)
4 Connect the [ terminal of the car battery.
5 Press to turn on the power.
6 Detach the faceplate and reset the unit. ( 3)
Auxiliary

Frequency Response (±3dB) 20Hz—20kHz
Input Maximum Voltage 1000mV
Input Impedance 30kΩ
Audio
Maximum Output Power 50W×4
Full Bandwidth Power 22W×4 (at less than 1% THD)
Speaker Impedance 4Ω—8Ω
Tone Action Band 1: 62.5Hz±9dB
Band 2: 100Hz±9dB
Band 3: 160 Hz±9dB
Band 4: 250 Hz±9dB
Band 5: 400 Hz±9dB
Band 6: 630Hz±9dB
Band 7: 1kHz±9dB
Band 8: 1.6kHz±9dB
Band 9: 2.5kHz±9dB
Band 10: 4kHz±9dB
Band 11: 6.3kHz±9dB
Band 12: 10kHz±9dB
Band 13: 16kHz±9dB
Preout Level/Load (CD)
: 4000mV/10kΩ
: 2500mV/10kΩ
Preout Impedance ≤600Ω
General
Operating Voltage 14.4V (10.5V—16V allowable)
Maximum Current Consumption 10A
Operational Temperature Range –10°C—+60°C
Installation Size (W×H×D) 182mm×53mm×158mm
Net Weight (includes Trimplate,
Mounting Sleeve)
1.3kg
SPECIFICATIONS
JS_KWD_KDC_BT610U_MN_EN_4.indd 29JS_KWD_KDC_BT610U_MN_EN_4.indd 29 26-Aug-16 5:21:10 PM26-Aug-16 5:21:10 PM

Kenwood KDC-BT510U Specifications

General

Brand	Kenwood
Model	KDC-BT510U
Category	Car Receiver
Language	English
