Kenwood KRF-V5200D Service Manual

PARTS LIST
Indicates safety critical components.
Ref. No.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
KRF-V5200D
34
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
Ref. No.
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
Indicates safety critical components.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
R818 RK73GB2A223J CHIP R 22K J 1/10W R819 RK73GB2A151J CHIP R 150 J 1/10W R820 RK73GB2A1R0J CHIP R 1.0 J 1/10W R821 RK73GB2A222J CHIP R 2.2K J 1/10W R822 RK73GB2A473J CHIP R 47K J 1/10W R823 RK73GB2A102J CHIP R 1.0K J 1/10W R824 RK73GB2A472J CHIP R 4.7K J 1/10W R825 RK73GB2A102J CHIP R 1.0K J 1/10W R826 RK73GB2A103J CHIP R 10K J 1/10W R831,832 RK73GB2A2R2J CHIP R 2.2 J 1/10W R833,834 RK73GB2A121J CHIP R 120 J 1/10W R835 RK73GB2A122J CHIP R 1.2K J 1/10W R836 RK73GB2A682J CHIP R 6.8K J 1/10W R837 RK73GB2A102J CHIP R 1.0K J 1/10W R838 RK73GB2A822J CHIP R 8.2K J 1/10W R839 RK73GB2A222J CHIP R 2.2K J 1/10W R840 RK73GB2A2R2J CHIP R 2.2 J 1/10W R841 RK73GB2A101J CHIP R 100 J 1/10W R851 RK73GB2A222J CHIP R 2.2K J 1/10W R852 RK73GB2A103J CHIP R 10K J 1/10W R853 RK73GB2A101J CHIP R 100 J 1/10W R854,855 RK73GB2A103J CHIP R 10K J 1/10W R856 RK73GB2A222J CHIP R 2.2K J 1/10W R861 RK73GB2A222J CHIP R 2.2K J 1/10W R862 RK73GB2A103J CHIP R 10K J 1/10W R863 RK73GB2A101J CHIP R 100 J 1/10W R864,865 RK73GB2A103J CHIP R 10K J 1/10W R866,867 RK73GB2A222J CHIP R 2.2K J 1/10W R871 RK73GB2A102J CHIP R 1.0K J 1/10W R872,873 RK73GB2A104J CHIP R 100K J 1/10W R874 RK73GB2A102J CHIP R 1.0K J 1/10W R875 RK73GB2A103J CHIP R 10K J 1/10W R876 RK73GB2A102J CHIP R 1.0K J 1/10W R877 RK73GB2A244J CHIP R 240K J 1/10W R878 RK73GB2A104J CHIP R 100K J 1/10W R881 RK73GB2A1R0J CHIP R 1.0 J 1/10W R882 RK73GB2A104J CHIP R 100K J 1/10W R883 RK73GB2A474J CHIP R 470K J 1/10W R885 RK73GB2A2R2J CHIP R 2.2 J 1/10W R886 RK73GB2A100J CHIP R 10 J 1/10W R891 RK73GB2A561J CHIP R 560 J 1/10W R892 RK73GB2A223J CHIP R 22K J 1/10W R893 RK73GB2A1R0J CHIP R 1.0 J 1/10W R921,922 RK73GB2A000J CHIP R 0.0 J 1/10W D301 DA204U DIODE D311 DA204U DIODE D331 DA204U DIODE D401 UDZS4.7B ZENER DIODE D421,422 DA204U DIODE D571 1SS355 DIODE D595 1SS355 DIODE D601 1SS355 DIODE D801 UDZS5.6B ZENER DIODE D811 UDZS5.6B ZENER DIODE
D815 UDZS3.9B ZENER DIODE D821 UDZS3.9B ZENER DIODE D822-824 1SS355 DIODE D831 UDZS2.4B ZENER DIODE D851 UDZS3.3B ZENER DIODE D852 1SS355 DIODE D861 UDZS3.3B ZENER DIODE D862-864 1SS355 DIODE D871-875 1SS355 DIODE IC11 NJM4565MD-ZB ANALOGUE IC IC31 NJM4565MD-ZB ANALOGUE IC IC51 NJM4565MD-ZB ANALOGUE IC IC91 NJM4565MD-ZB ANALOGUE IC IC111 NJM4565MD-ZB ANALOGUE IC IC121 NJU7311AM-ZB ANALOGUE IC IC151
✽
R2S15205FP ANALOGUE IC
IC171 NJM4565MD-ZB ANALOGUE IC IC181 NJM4565MD-ZB ANALOGUE IC IC191 NJM4565MD-ZB ANALOGUE IC IC401 AK4586VQP MOS-IC IC501 CS493263-CLZ MOS-IC IC551
✽
74HC3GU04DP MOS-IC
IC571 TC7WH123FU-F MOS-IC IC601
✽
MN101C49KDF MICROCONTROLLER IC
IC721 TC74HCT7007FF MOS-IC IC731 TC74HCT7007FF MOS-IC IC741 TC74HCT7007FF MOS-IC IC761 LC72725KV ANALOGUE IC IC801 KIA7805API-P ANALOGUE IC IC805 KIA7805API-P ANALOGUE IC IC811
✽
XC6206P332PRN ANALOGUE IC
IC815 XC62EP2502MRN ANALOGUE IC IC871 XC61CN2702MRN ANALOGUE IC IC881 XC62HR4102PRN ANALOGUE IC Q361 2SC4213(B)-F TRANSISTOR Q371,372 2SC4213(B)-F TRANSISTOR Q375,376 2SC4213(B)-F TRANSISTOR Q571 DTC124EUA DIGITAL TRANSISTOR Q815 2SB1375-F TRANSISTOR Q821 2SA1576A(R,S) TRANSISTOR Q822 2SC4081(R,S) TRANSISTOR Q831 2SC2003-A(L,K) TRANSISTOR Q832 2SA954-A(L,K) TRANSISTOR Q833,834 2SK879-F(Y,GR FET Q835 2SC4081(R,S) TRANSISTOR Q836 2SA1576A(R,S) TRANSISTOR Q851 2SA1576A(R,S) TRANSISTOR Q861 2SA1576A(R,S) TRANSISTOR Q871 2SA1576A(R,S) TRANSISTOR Q872 2SC4081(R,S) TRANSISTOR Q891 2SB1375-F TRANSISTOR A591,592 W02-4652-05 OPTIC RECEIVING MODULE
