Kenwood KRF-V5200D Service Manual

PARTS LIST
KRF-V5200D
35
Indicates safety critical components.
Ref. No.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
Ref. No.
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
Indicates safety critical components.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
C1,2 CC73GCH1H102J CHIP C 1000PF J C3,4 CD04BJ1H2R2M ELECTRO 2.2UF 50WV C5,6 CC73GCH1H471J CHIP C 470PF J C7,8 CC73GCH1H391J CHIP C 390PF J C9,10 CD04BJ1V330M ELECTRO 33UF 35WV C11,12 CC73GCH1H270J CHIP C 27PF J C17-20 CK73GB1H223K CHIP C 0.022UF K C25,26 CD04BJ1H2R2M ELECTRO 2.2UF 50WV C27,28 CC73GCH1H471J CHIP C 470PF J C29,30 CC73GCH1H391J CHIP C 390PF J C31,32 CD04BJ1V330M ELECTRO 33UF 35WV C33,34 CC73GCH1H270J CHIP C 27PF J C35-38 C91-1577-05 MP-C 0.22UF J C39-42 CK73GB1H223K CHIP C 0.022UF K C44 CK73GB1H223K CHIP C 0.022UF K C46 CK73GB1H223K CHIP C 0.022UF K C47-51 CD04BJ1H100M ELECTRO 10UF 50WV C101 CD04BJ1H2R2M ELECTRO 2.2UF 50WV C102 CC73GCH1H471J CHIP C 470PF J C103 CC73GCH1H391J CHIP C 390PF J C104 CD04BJ1V330M ELECTRO 33UF 35WV C105 CC73GCH1H270J CHIP C 27PF J C106,107 C91-1577-05 MP-C 0.22UF J C243-246 C91-1577-05 MP-C 0.22UF J C301 CD04AU1H2R2M NP-ELEC 2.2UF 50WV C302 CD04BJ1E470M ELECTRO 47UF 25WV C303 CD04BJ1H100M ELECTRO 10UF 50WV C304 CD04BJ1H010M ELECTRO 1.0UF 50WV C305 CD04BJ1V330M ELECTRO 33UF 35WV C306 CD04BJ1A101M ELECTRO 100UF 10WV C307 CD04BJ1H010M ELECTRO 1.0UF 50WV C308 CD04BJ1H100M ELECTRO 10UF 50WV C309 CD04BJ1E470M ELECTRO 47UF 25WV C311-315 CK73GB1H472K CHIP C 4700PF K C501,502 C91-1567-05 FILM 0.1UF J C503,504 C90-5775-05 ELECTRO 4700UF 75WV C505,506 CQ93FMG1H104J MYLAR 0.10UF J C507 CD04BJ1E222M1 ELECTRO 2200UF 25WV C508 CD04BJ1E471M1 ELECTRO 470UF 25WV C509,510 CK73GB1H104K CHIP C 0.10UF K C511 CD04BJ1E101M ELECTRO 100UF 25WV C512 CD04BJ1E470M ELECTRO 47UF 25WV C513 CD04BJ1J471M1 ELECTRO 470UF 63WV C514 CD04BJ1J330M ELECTRO 33UF 63WV C515 CD04BJ1J470M ELECTRO 47UF 63WV C516 CK45FF1H103Z CERAMIC 0.010UF Z C517 CD04BJ1C472M1 ELECTRO 4700UF 16WV C518 CD04BJ1H100M ELECTRO 10UF 50WV C519 CD04BJ1H470M ELECTRO 47UF 50WV C520 CK73GB1H223K CHIP C 0.022UF K C522,523 CD04BJ2A100M ELECTRO 10UF 100WV C524,525 CD04BJ1J330M ELECTRO 33UF 63WV C526,527 CK73GB1H104K CHIP C 0.10UF K
CN3
✽
E41-1443-05 FLAT CABLE CNNCTR, 1.25MM, 29P
J2,3
✽
E70-1032-05 LOCK TERMINAL BOARD, 4P
J4
✽
E70-1031-05 LOCK TERMINAL BOARD, 2P
E1 J11-0898-05 WIRE CLAMPER L3-7
✽
L39-1631-05+ PHASE COMPENSATION COIL
R1,2 RK73GB2A222J CHIP R 2.2K J 1/10W R3 RK73GB2A473J CHIP R 47K J 1/10W R4 RK73GB2A1R0J CHIP R 1.0 J 1/10W R5,6 RK73GB2A222J CHIP R 2.2K J 1/10W R11,12 RK73GB2A104J CHIP R 100K J 1/10W R13,14 RK73GB2A563J CHIP R 56K J 1/10W R15,16 RK73GB2A101J CHIP R 100 J 1/10W R17,18 RK73GB2A182J CHIP R 1.8K J 1/10W R19,20 RK73GB2A102J CHIP R 1.0K J 1/10W R23-26 RS14KB3DR22J FL-PROOF RS 0.22 J 2W R31,32 RS14KB3D391J FL-PROOF RS 390 J 2W R33,34 RK73GB2A222J CHIP R 2.2K J 1/10W R35,36 RK73GB2A104J CHIP R 100K J 1/10W R37,38 RK73GB2A563J CHIP R 56K J 1/10W R39,40 RK73GB2A101J CHIP R 100 J 1/10W R41,42 RK73GB2A182J CHIP R 1.8K J 1/10W R43,44 RK73GB2A102J CHIP R 1.0K J 1/10W R47-50 RS14KB3DR22J FL-PROOF RS 0.22 J 2W R51,52 RD14NB2E4R7J RD 4.7 J 1/4W R53,54 RS14KB3D4R7J FL-PROOF RS 4.7 J 2W R61 RK73GB2A000J CHIP R 0.0 J 1/10W R69,70 RK73GB2A122J CHIP R 1.2K J 1/10W R101 RK73GB2A222J CHIP R 2.2K J 1/10W R102 RK73GB2A104J CHIP R 100K J 1/10W R103 RK73GB2A563J CHIP R 56K J 1/10W R104 RK73GB2A101J CHIP R 100 J 1/10W R105 RK73GB2A182J CHIP R 1.8K J 1/10W R106 RK73GB2A102J CHIP R 1.0K J 1/10W R108,109 RS14KB3DR22J FL-PROOF RS 0.22 J 2W R110 RD14NB2E4R7J RD 4.7 J 1/4W R111 RS14KB3D4R7J FL-PROOF RS 4.7 J 2W R112 RK73GB2A153J CHIP R 15K J 1/10W R113 RK73GB2A333J CHIP R 33K J 1/10W R259-264 RK73GB2A473J CHIP R 47K J 1/10W R265,266 RD14NB2E4R7J RD 4.7 J 1/4W R267,268 RS14KB3D4R7J FL-PROOF RS 4.7 J 2W R301 RK73GB2A272J CHIP R 2.7K J 1/10W R302-305 RK73GB2A103J CHIP R 10K J 1/10W R306 RK73GB2A104J CHIP R 100K J 1/10W R307 RK73GB2A330J CHIP R 33 J 1/10W R308 RK73GB2A104J CHIP R 100K J 1/10W R309 RK73GB2A102J CHIP R 1.0K J 1/10W R310 RK73GB2A183J CHIP R 18K J 1/10W R311 RK73GB2A104J CHIP R 100K J 1/10W R312 RK73GB2A183J CHIP R 18K J 1/10W R313 RK73GB2A104J CHIP R 100K J 1/10W R314 RK73GB2A222J CHIP R 2.2K J 1/10W R315 RK73GB2A152J CHIP R 1.5K J 1/10W
AUDIO (X09-7032-70)
11 12

Kenwood KRF-V5200D Specifications
