Kenwood KRF-V5200D Service Manual

PARTS LIST
Indicates safety critical components.
Ref. No.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
KRF-V5200D
36
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
Ref. No.
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
Indicates safety critical components.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
R320 RK73GB2A152J CHIP R 1.5K J 1/10W R321 RK73GB2A102J CHIP R 1.0K J 1/10W R322 RK73GB2A473J CHIP R 47K J 1/10W R323 RK73GB2A102J CHIP R 1.0K J 1/10W R324 RK73GB2A473J CHIP R 47K J 1/10W R325 RK73GB2A333J CHIP R 33K J 1/10W R326 RK73GB2A221J CHIP R 220 J 1/10W R327 RK73GB2A103J CHIP R 10K J 1/10W R328 RK73GB2A102J CHIP R 1.0K J 1/10W R329,330 RK73GB2A473J CHIP R 47K J 1/10W R331 RK73GB2A332J CHIP R 3.3K J 1/10W R333 RK73GB2A473J CHIP R 47K J 1/10W R335,336 RK73GB2A473J CHIP R 47K J 1/10W R340,341 RK73GB2A473J CHIP R 47K J 1/10W R344 RK73GB2A473J CHIP R 47K J 1/10W R345 RK73GB2A333J CHIP R 33K J 1/10W R346 RK73GB2A473J CHIP R 47K J 1/10W R347 RK73GB2A362J CHIP R 3.6K J 1/10W R349-351 RK73GB2A471J CHIP R 470 J 1/10W R352-354 RK73GB2A912J CHIP R 9.1K J 1/10W R355-357 RK73GB2A303J CHIP R 30K J 1/10W R358,359 RK73GB2A471J CHIP R 470 J 1/10W R360,361 RK73GB2A912J CHIP R 9.1K J 1/10W R362,363 RK73GB2A303J CHIP R 30K J 1/10W R364 RK73GB2A102J CHIP R 1.0K J 1/10W R367 RK73GB2A102J CHIP R 1.0K J 1/10W R371,372 RK73GB2A102J CHIP R 1.0K J 1/10W R501 RD14NB2E1R0J RD 1.0 J 1/4W R503 RK73GB2A471J CHIP R 470 J 1/10W R504 RK73GB2A4R7J CHIP R 4.7 J 1/10W R505,506 RK73GB2A473J CHIP R 47K J 1/10W R508 RD14NB2E222J RD 2.2K J 1/4W R510 RS14KB3D470J FL-PROOF RS 47 J 2W R512 RK73GB2A473J CHIP R 47K J 1/10W R513 RK73GB2A2R2J CHIP R 2.2 J 1/10W R514,515 RK73GB2A1R0J CHIP R 1.0 J 1/10W R517 RD14NB2E822J RD 8.2K J 1/4W R518 RS14KB3D102J FL-PROOF RS 1.0K J 2W R519,520 RS14KB3D332J FL-PROOF RS 3.3K J 2W R522 RD14NB2E182J RD 1.8K J 1/4W R523 RS14KB3D331J FL-PROOF RS 330 J 2W R524 RK73GB2A561J CHIP R 560 J 1/10W R526 RK73GB2A473J CHIP R 47K J 1/10W R527,528 RD14NB2E1R0J RD 1.0 J 1/4W R529-533 RK73GB2A1R0J CHIP R 1.0 J 1/10W R702,703 RK73GB2A000J CHIP R 0.0 J 1/10W R802 RK73GB2A000J CHIP R 0.0 J 1/10W R804 RK73GB2A000J CHIP R 0.0 J 1/10W K1,2 S76-0097-05 MAGNETIC RELAY K4,5 S76-0097-05 MAGNETIC RELAY D3-7 1SS133 DIODE D301,302 UDZS3.3B ZENER DIODE D304 DAN202U DIODE D305 UDZS3.3B ZENER DIODE
D306 1SS133 DIODE D307 DAP202U DIODE D308 1SS133 DIODE D309,310 DAN202U DIODE D311,312 1SS133 DIODE D314,315 DAN202U DIODE D316,317 1SS133 DIODE D319,320 1SS133 DIODE D322 1SS355 DIODE D501 TS6P03G-B DIODE D502-507 S5688B(TPB5)Q DIODE D508 MTZJ16(B) ZENER DIODE D509 MTZJ15(B) ZENER DIODE D510 TS4B03G-B1 DIODE D511 1SS355 DIODE D512 UDZS11B ZENER DIODE D513 UDZS6.2B ZENER DIODE D514 1SS133 DIODE D515 S5688B(TPB5)Q DIODE D516,517 UDZS15B ZENER DIODE D518,519 UDZS7.5B ZENER DIODE D520 UDZS16B ZENER DIODE D521
✽
UDZS30B ZENER DIODE
D522 MTZJ3.9(B) ZENER DIODE D523 1SS355 DIODE D524 UDZS5.6B ZENER DIODE D525 UDZS5.1B ZENER DIODE IC1
✽
STK433-330-E HYBRID IC,19P, 3CH AF PWR-AMP
IC2
✽
STK433-130-E HYBRID IC,15P, 2CH AF PWR-AMP
IC3 KIA7812API-UP ANALOGUE IC IC4 KIA7912API-UP ANALOGUE IC Q1,2 DTC643TU DIGITAL TRANSISTOR Q5-8 DTC643TU DIGITAL TRANSISTOR Q101 DTC643TU DIGITAL TRANSISTOR Q301,302 2SA1576A(R,S) TRANSISTOR Q303,304 2SC4081(R,S) TRANSISTOR Q305 2SA1576A(R,S) TRANSISTOR Q306,307 2SC4081(R,S) TRANSISTOR Q308 2SA1576A(R,S) TRANSISTOR Q309-313 2SC1845-A(F,E) TRANSISTOR Q314,315 DTC113ZUA DIGITAL TRANSISTOR Q317,318 DTC113ZUA DIGITAL TRANSISTOR Q501 2SB1640-Q TRANSISTOR Q502 2SC4081(R,S) TRANSISTOR Q503 2SA1576A(R,S) TRANSISTOR Q504 2SB1640-Q TRANSISTOR Q505 2SA1576A(R,S) TRANSISTOR Q506 2SD2525-Q TRANSISTOR Q507 2SB1640-Q TRANSISTOR Q508 2SK879-F(Y,GR FET Q510 2SC4081(R,S) TRANSISTOR TH1 NCP18WB473J0S THERMISTOR TH3 NCP18WB473J0S THERMISTOR
13 14
