Kenwood KRF-V5200D Service Manual

PARTS LIST
KRF-V5200D
37
Indicates safety critical components.
Ref. No.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
Ref. No.
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
Indicates safety critical components.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
D102-104 B30-2597-05 LED (LED RED (HIGH)) D106 B30-2597-05 LED (LED RED (HIGH)) D108 B30-2684-05 LED (LED BLUE 3PHI) C101 CC73GCH1H101J CHIP C 100PF J C102 CK73GB1H103K CHIP C 0.010UF K C103 CD04BJ1A101M ELECTRO 100UF 10WV C104,105 CD04BJ1H2R2M ELECTRO 2.2UF 50WV C106 CD04AU1H220M NP-ELEC 22UF 50WV C107,108 CK73GB1H103K CHIP C 0.010UF K C109 CC73GCH1H102J CHIP C 1000PF J C110,111 CK73GB1H103K CHIP C 0.010UF K C112 CD04BJ1J330M ELECTRO 33UF 63WV C113,114 CC73GCH1H101J CHIP C 100PF J C115 CD04BJ1H470M ELECTRO 47UF 50WV C116-118 CC73GCH1H101J CHIP C 100PF J C119 CD04BJ1A101M ELECTRO 100UF 10WV C120 CC73GCH1H101J CHIP C 100PF J C121,122 CC73GCH1H100D CHIP C 10PF D C131,132 CD04BJ1H2R2M ELECTRO 2.2UF 50WV C201 CK73GB1H103K CHIP C 0.010UF K C202 CD04BJ1C332M1 ELECTRO 3300UF 16WV C203 CK73GB1H103K CHIP C 0.010UF K C204 C91-1643-05 MF-C 6800PF J C301-303 CC73GCH1H101J CHIP C 100PF J C305,306 CC73GCH1H102J CHIP C 1000PF J C307 CC73GCH1H101J CHIP C 100PF J C311,312 CK73GB1H103K CHIP C 0.010UF K C321,322 CK73GB1A105K CHIP C 1.0UF K C323,324 CC73GCH1H220J CHIP C 22PF J C325,326 CK73GB1H104K CHIP C 0.10UF K C401,402 CK73GB1H104K CHIP C 0.10UF K C403 CD04BJ1E470M ELECTRO 47UF 25WV C406,407 CK73GB1H104K CHIP C 0.10UF K C408 CD04BJ1E470M ELECTRO 47UF 25WV C640 CD04BJ1E470M ELECTRO 47UF 25WV C641 CK73GB1H472K CHIP C 4700PF K C642 CK73GB1H103K CHIP C 0.010UF K C643 CK73GB1H472K CHIP C 4700PF K C644 CK73GB1H103K CHIP C 0.010UF K C645-647 CD04BJ1E470M ELECTRO 47UF 25WV C648,649 CC73GCH1H101J CHIP C 100PF J C650-652 CC73GCH1H470J CHIP C 47PF J C701-703 CK73GB1H104K CHIP C 0.10UF K X C704 CD04BJ1H010M ELECTRO 1.0UF 50WV X C705,706 CK73GB1H103K CHIP C 0.010UF K X C707 CD04BJ1A471M ELECTRO 470UF 10WV X C708 CD04BJ1H010M ELECTRO 1.0UF 50WV X C709,710 CK73GB1H103K CHIP C 0.010UF K X C711 CD04BJ1A471M ELECTRO 470UF 10WV X C712 CD04BJ1H010M ELECTRO 1.0UF 50WV X C713,714 CK73GB1H103K CHIP C 0.010UF K X C715 CD04BJ1A471M ELECTRO 470UF 10WV X C716 CD04BJ1H010M ELECTRO 1.0UF 50WV X
C717,718 CK73GB1H103K CHIP C 0.010UF K X C719,720 CD04BJ1H010M ELECTRO 1.0UF 50WV X C721,722 CK73GB1H103K CHIP C 0.010UF K X C723,724 CD04BJ1H010M ELECTRO 1.0UF 50WV X C725,726 CK73GB1H103K CHIP C 0.010UF K X C727 CD04BJ1H010M ELECTRO 1.0UF 50WV X C728-734 CC73GCH1H100D CHIP C 10PF D X C735 CC73GCH1H820J CHIP C 82PF J X C736 CC73GCH1H100D CHIP C 10PF D X C737 CC73GCH1H820J CHIP C 82PF J X C738 CC73GCH1H100D CHIP C 10PF D X C739 CC73GCH1H820J CHIP C 82PF J X C901,902 CC73GCH1H471J CHIP C 470PF J CN101
✽
E41-1470-05 FLAT CABLE CNNCTR, 1.25MM, 27P
J302 E63-1388-05 PIN JACK, 3P, BLK/BLK/BLK J601 E63-1371-05 PIN JACK, 2P2L, YEL, NI, LF J602 E63-1368-05 PIN JACK, 3P, YEL, NI, LF J701,702
✽
E63-1414-05 PIN JACK, VERTICAL 3P
✽
2 X
J901 E11-0271-05 PHONE JACK (METAL SLEEVE) F201 F50-0332-05 FUSE, T3.15A, L 250V
CN203,204
J13-0075-05 FUSE CLIP, 5X20
E2 J11-0898-05 WIRE CLAMPER T201 L07-2980-05 POWER TRANSFORMER, 220V, 7V/10MA X101 L78-0747-05 RESONATOR (4MHZ) R102,103 RD14BB2C221J RD 220 J 1/6W R106 RK73GB2A100J CHIP R 10 J 1/10W R107 RK73GB2A101J CHIP R 100 J 1/10W R111 RK73GB2A104J CHIP R 100K J 1/10W R112 RK73GB2A2R2J CHIP R 2.2 J 1/10W R113-119 RK73GB2A104J CHIP R 100K J 1/10W R124 RK73GB2A473J CHIP R 47K J 1/10W R129 RK73GB2A473J CHIP R 47K J 1/10W R132 RK73GB2A473J CHIP R 47K J 1/10W R136 RK73GB2A473J CHIP R 47K J 1/10W R139 RK73GB2A473J CHIP R 47K J 1/10W R141 RK73GB2A2R2J CHIP R 2.2 J 1/10W R143-145 RK73GB2A101J CHIP R 100 J 1/10W R149 RK73GB2A104J CHIP R 100K J 1/10W R153,154 RK73GB2A100J CHIP R 10 J 1/10W R161 RK73GB2A102J CHIP R 1.0K J 1/10W R201 RD14NB2E1R0J RD 1.0 J 1/4W R202 RD14NB2E330J RD 33 J 1/4W R211 RK73GB2A2R2J CHIP R 2.2 J 1/10W R301-303 RK73GB2A101J CHIP R 100 J 1/10W R305,306 RK73GB2A104J CHIP R 100K J 1/10W R307 RK73GB2A750J CHIP R 75 J 1/10W R321,322 RK73GB2A104J CHIP R 100K J 1/10W R323-326 RK73GB2A100J CHIP R 10 J 1/10W R402 RK73GB2A332J CHIP R 3.3K J 1/10W R403 RK73GB2A223J CHIP R 22K J 1/10W R407 RS14KB3D821J FL-PROOF RS 820 J 2W X R413 RS14KB3D821J FL-PROOF RS 820 J 2W X
DISPLAY (X14-805x-xx)
15 16
