Kenwood MDX-F1 Service Manual

MDX-F1
40
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
- ✽ H50-3668-04 ITEM CARTON CASE M2
660 1D ✽ J02-1470-05 INSULATOR BLUE
661 1D ✽ J02-1471-05 INSULATOR PINK
662 1C ✽ J11-0852-03 CLAMPER ASSY
664 1D J19-5919-05 UNIT HOLDER
671 2C J52-0039-05 PUSH LATCH
679 1D J61-0070-05 WIRE BAND
- J61-0307-05 WIRE BAND
680 1D ✽ K01-0110-02 HANDLE M1
680 1D ✽ K01-0117-02 HANDLE M2
681 2C,2D ✽ K29-7669-02 KNOB
682 2C ✽ K29-7670-04 KNOB M1
682 2C ✽ K29-7759-04 KNOB M2
683 2C ✽ K29-7718-03 KNOB M1
683 2C ✽ K29-7750-03 KNOB M2
684 2C ✽ K29-7753-04 KNOB ASSY M1
684 2C ✽ K29-7755-04 KNOB ASSY M2
687 2D ✽ L07-2782-05 POWER TRANSFORMER
693 1E T90-0828-05 ROD ANTENNA
694 1C ✽ T90-0852-05 LOOP ANTENNA
SP1 2C ✽ T07-0096-05 FULLRANGE L
SP2 2D ✽ T07-0097-05 FULLRANGE R
D503 B30-2541-05 LED(GRN3(80))
D504 B30-2567-05 LED(RED(80) HI-BR)
C1 CE04KW1A332M ELECTRO 3300UF 10WV
C2 CK73FB1H563K CHIP C 0.056UF K
C4 CE04KW1E470M ELECTRO 47UF 25WV
C5 CE04KW1H010M ELECTRO 1.0UF 50WV
C11 ,12 CE04KW1E222M ELECTRO 2200UF 25WV
C13 CK73FB1H473K CHIP C 0.047UF K
C14 CK73FB1H102K CHIP C 1000PF K
C15 CE04KW1C222M ELECTRO 2200UF 16WV
C16 CK73FB1H683K CHIP C 0.068UF K
C17 CE04KW1E470M ELECTRO 47UF 25WV
C18 CK73FB1H102K CHIP C 1000PF K
C19 CE04DW1J101M ELECTRO 100UF 63WV
C20 CE04KW1J330M ELECTRO 33UF 63WV
C21 CK73FB1H102K CHIP C 1000PF K
C23 CK73FB1H332K CHIP C 3300PF K
C101 CK73FB1H103K CHIP C 0.010UF K
C102 CE04KW1E470M ELECTRO 47UF 25WV
C103 CE04KW1C331M ELECTRO 330UF 16WV
C105 CK73FB1H103K CHIP C 0.010UF K
C107 CK73FF1E104Z CHIP C 0.10UF Z
C109,110 CC73FCH1H221J CHIP C 220PF J
C151,152 CK73FB1H472K CHIP C 4700PF K
C153,154 CK73FB1H332K CHIP C 3300PF K
C155 CK73FF1C105Z CHIP C 1.0UF Z
C156 CK73FB1H103K CHIP C 0.010UF K
C157 CK73FB1H102K CHIP C 1000PF K
C201 CE04KW1A101M ELECTRO 100UF 10WV
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
601 1E ✽ A02-2949-01 PLASTIC CABINET M1
601 1E ✽ A02-2950-01 PLASTIC CABINET M2
602 1C A09-1151-08 BATTERY COVER
603 1D ✽ A21-3816-02 DRESSING PANEL L M1
603 1D ✽ A21-3830-02 DRESSING PANEL L M2
604 1D ✽ A21-3817-02 DRESSING PANEL R M1
604 1D ✽ A21-3831-02 DRESSING PANEL R M2
605 1D ✽ A21-3818-04 DRESSING PANEL KENWOOD M1
605 1D ✽ A21-3837-04 DRESSING PANEL KENWOOD M2
606 1C ✽ A22-1836-01 SUB PANEL
607 2D ✽ A29-1078-04 PANEL
608 1D ✽ A52-0378-02 DOOR ASSY M1
608 1D ✽ A52-0380-02 DOOR ASSY M2
609 2C ✽ A53-2174-02 CASSETTE HOLDER M1
609 2C ✽ A53-2188-02 CASSETTE HOLDER M2
610 2D ✽ A60-1729-02 PANEL ASSY M1
610 2D ✽ A60-1803-02 PANEL ASSY M2
611 1C ✽ A70-1325-05 REMOTE CONTROL(RC-MDX0101)
615 2C ✽ B07-2482-04 ESCUTCHEON
616 2C ✽ B10-3540-04 FRONT GLASS
617 2C ✽ B10-3541-03 FRONT GLASS
618 2C ✽ B12-0381-04 INDICATOR
- B58-0966-13 CAUTION CARD (PL)
- B58-1643-04 CAUTION CARD (CASSETTE EJEC)
- ✽ B60-4535-00 INSTRUCTION MANUAL
621 1D ✽ D21-1967-04 SHAFT
622 2C,2D D39-0333-05 DAMPER
623 2E ✽ D40-1655-05 MECHANISM ASSY CASSETTE
624 2E ✽ D40-1656-05 MECHANISM ASSY MDM-99A
625 1D ✽ D40-1660-05 MECHANISM ASSY CD
629 2E ✽ E35-2457-05 WIRING HARNESS, 7P,HEAD,DECK
630 1D,1E E35-2243-05 FLAT CABLE 16P,CD
631 2D,2E ✽ E35-2443-05 FLAT CABLE 13P DISPLAY
632 1E,2E ✽ E35-2445-05 FLAT CABLE 12P,DECK
634 2D,2E ✽ E35-2463-05 FLAT CABLE 5P
635 2D,2E ✽ E35-2464-05 FLAT CABLE 7P
647 2D ✽ G01-4194-04 EXTENSION SPRING
648 1D ✽ G01-4195-04 TORSION COIL SPRING
649 2E ✽ G01-4196-04 TORSION COIL SPRING
650 2C,1E G10-0146-04 NON-WOVEN FABRIC,30X10X0.5
651 2E G10-0461-04 NON-WOVEN FABRIC
652 1D ✽ G10-0518-04 NON-WOVEN FABRIC,SP L
653 2E ✽ G10-0519-04 NON-WOVEN FABRIC,SP R
655 1E ✽ G11-2712-04 CUSHION FOOT
656 1D ✽ G11-2713-04 CUSHION HANDLE
- ✽ H10-7622-02 POLYSTYRENE FOAMED FIXTURE
- ✽ H10-7623-02 POLYSTYRENE FOAMED FIXTURE
- ✽ H13-0326-04 CARTON BOARD
- ✽ H21-0367-04 PROTECTION SHEET
- H25-1642-04 PROTECTION BAG
- ✽ H50-3630-04 ITEM CARTON CASE M1
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
MDX-F1 M1: SILVER, M2: RED
AUDIO (X09-6400-21)

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
