Kenwood MDX-F1 Service Manual

MDX-F1
PARTS LIST
SPECIFICATIONS
14-6,Dogenzaka 1-chome, Shibuya-ku, Tokyo, 150-8501 Japan
KENWOOD SERVICE CORPORATION
P.O BOX 22745, 2201 East Dominguez St., Long Beach, CA 90801-5745, U.S.A.
Note:
Component and circuit are subject to modification to insure best operation
under differing local conditions. This manual is based on Europe (E) standard,
and provides information on regional circuit modification through use of alter-
nate schematic diagrams, and information on regional component variations
through use of parts list.
[Amplifier section]
Rated output power during STEREO operation
10 % T.H.D., at 4 ‰.................................... 4 W + 4 W
[Tuner section]
FM tuner section
Tuning frequency range ............. 87.5 MHz ~ 108 MHz
MW (AM) tuner section
Tuning frequency range ............. 531 kHz ~ 1,602 kHz
[MD recorder section]
Laser ................................................ Semiconductor laser
Recording method
.............................. Field modulation overwrite method
Audio compression................................................ ATRAC
D/A Conversion .......................................................... 1 Bit
Wow & flutter...................... Less than unmeasurable limit
[CD player section]
Laser ................................................ Semiconductor laser
D/A Conversion .......................................................... 1 Bit
Oversampling ...........................................8 fs (352.8 kHz)
Frequency response ................................. 20 Hz~20 kHz
Wow and flutter .................. Less than unmeasurable limit
Main unit
Enclosure ............................................... Bass-reflex type
Speaker configuration
Speaker unit ................................... 80 mm, cone type
KENWOOD follows a policy of continuous advancements in development. For reason specifications may be
changed without notice.
÷ The full performance may not be exhibited in an extremely cold location (under a water-freezing temperature).
Speakers
[Cassette deck section]
Track ......................................... 4-track, 2-channel stereo
Recording system .................................... AC bias system
(Frequency: 105 kHz)
Heads
Playback / recording head ......................................... 1
Erasing head .............................................................. 1
Motors ............................................................................. 1
Fast winding time ............................ Approx. 100 seconds
(C-60 tape)
[General]
Power consumption.................................................. 38 W
Standby power consumption................................... 0.3 W
Dimensions .................................................. W: 464 mm
H : 182 mm
D : 243 mm
Weight (net)............................................................
5.4 kg
Notes
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
BD N39-1750-45 SCREW(1.7X5) LX-BZ0883AFZZ BE ✽ N09-5197-08 SCREW(1.4X3) LX-JZ0020AWZZ BF ✽ N09-5198-08 SCREW(1.7X6) LX-JZ0022AWZZ BG ✽ N39-1445-45 SCREW(1.4X4.5) LX-JZ0024AWZZ BH ✽ N09-5199-08 SCREW(2X3) XBPSD20P03K00 BJ ✽ N09-5200-08 SCREW(1.7X3) XSPSN17P03K00 BK N16-0014-46 WASHER(1.5X3.2X0.5)XWSSD14-05000 BL N39-1730-45 SCREW(1.7X3) LX-BZ0846AFZZ BM N39-1450-45 SCREW(1.4X5) LX-JB0025AWZZ CN1300 ✽ E35-2588-08 WIRE HARNESS QCNWM1044AWZZ CN1931 E40-8211-08 CABLE CONN(5P) QCNCWXC05AFZZ CN1932 ✽ E40-8617-08 CABLE CONN(6P) QCNCWXC06AFZZ CW1501 2E,3B ✽ E35-2587-08 FFC(28P) QCNWN1549AWZZ CW1931 2A,3A ✽ E35-2589-08 FFC(5P) QCNWN1512AWZZ CW1932 3A ✽ E35-2590-08 FFC(6P) QCNWN1513AWZZ M901 3A ✽ T42-0974-08 DISC MOTOR RMOTV0025AWZZ M902 3A ✽ T42-0975-08 FEED MOTOR 92LMTR3167BASY M903 2B ✽ T42-0976-08 LOADING MOTOR 92LMTR3167AASY MDPU 2B ✽ T25-0099-08 PICKUP RCTRH8198AFZZ MDRH 2B ✽ T30-0025-08 RECORD HEAD RCILH0113AFZZ PWB-F 2A,3A ✽ J70-1414-08 PCB(MECHA) QPWBF0554AWZZ SW1930 2A ✽ S68-0126-08 PUSH SWITCH QSW-P0011AWZZ SW1931 2A ✽ S68-0127-08 PUSH SWITCH QSW-P0012AWZZ
SW1932-34
2A ✽ S64-0049-08 PUSH SWITCH QSW-M0007AWZZ
SW1936 3A ✽ S64-0050-08 PUSH SWITCH QSW-M0157AFZZ BM 2E PENDING BELT(MAIN) BR 2E PENDING BELT(REEL) PF 2E PENDING PINCH ROLLER ASSY (FWD) PR 2D PENDING PINCH ROLLER ASSY (RVS)
✽ New Parts Parts without Parts No. are not supplied. Les articles non mentionnes dans le Parts No. ne sont pas fournis. Teile ohne Parts No. werden nicht geliefert.
&
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai) Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
CASSETTE MECHANISM (D40-1655-05)

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
