Kenwood MDX-F1 Service Manual

MDX-F1
47
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
IC1101 IR3R55 IC
IC1201 LR376484 IC
IC1202 IX2474AF IC
IC1300 74ACT02T IC
IC1301 FTD2005 IC
IC1302 CPH5608 IC
IC1401 ✽ IX0342AW IC
IC1402 ✽ 58X2402T IC
IC1601 ✽ M56788F IC
IC1701 ✽ UDA1347 IC
IC1702 NJM431U IC(REGULATOR)
IC1801 XC62EP32 IC
Q1402 UN2113 TRANSISTOR
Q1403 UN2213 TRANSISTOR
Q1501 UN2214 TRANSISTOR
Q1700 ✽ U2SD601AR TRANSISTOR
Q1701 UN2213 TRANSISTOR
Q1702 2SA1162G TRANSISTOR
Q1800 UN2214 TRANSISTOR
Q1801 2SA1162G TRANSISTOR
Q1802 UN2214 TRANSISTOR
Q1803 ✽ UN221N TRANSISTOR
Q1804 ✽ 2SA1242Y TRANSISTOR
Q1805 2SA1314C TRANSISTOR
Q1806 ✽ UN221N TRANSISTOR
202 2A ✽ A10-3517-08 LD BASE LCHSM0089AWZZ
203 2B ✽ A11-1179-08 MD BASE LCHSM0090AWZZ
204 1A ✽ J19-6075-08 CRTRGE HLDR ASSY,LHLDX3005AWM1
205 1A ✽ D10-3941-08 SLIDER LVR ASSY,MLEVF0051AWM1
207 1A ✽ D10-3942-08 HOLDER ARM MLEVF0046AWFW
208 2A ✽ D10-3943-08 SWITCH PLATE MLEVF0047AWFW
209 2B ✽ D10-3944-08 H/A SHIFT ARM MLEVF0048AWFW
210 1A ✽ D10-3945-08 CAM PLATE LEVER,MLEVP0095AWZZ
212 1A ✽ G01-4200-08 LOADING SPRING MSPRD0132AWFJ
214 3B ✽ G02-1703-08 GRIP SPRING MSPRP0030AWFJ
215 3A ✽ G02-1704-08 SHAFT SPRING MSPRP0031AWFJ
216 1A ✽ G01-4201-08 LOADING ARM SP,MSPRT0031AWFJ
217 2A ✽ G01-4202-08 SHIFT ARM SP MSPRT0032AWFJ
218 1A ✽ D13-1992-08 LOADING GEAR(A) NGERH0085AFZZ
219 1A ✽ D13-1993-08 MID GEAR(A) NGERH0086AFZZ
220 1A ✽ D13-1994-08 MID GEAR(B) NGERH0087AFZZ
221 1A ✽ D13-1995-08 MID GEAR(C) NGERH0088AFZZ
222 2A ✽ D13-1996-08 MID GEAR(D) NGERH0089AFZZ
224 3B ✽ D13-1997-08 GRIP RACK NGERR0004AWZZ
227 3B ✽ D19-0322-08 DRIVE SCREW ASSY,NSFT0006AWM1
228 3B ✽ D10-3946-08 PICKUP GUDE SHFT,NSFTM0019AWFW
230 1B ✽ A01-3756-08 SHIELD CVR(TOP),PCOVS3029AWFW
231 2B ✽ A01-3757-08 SHIELD CVR(SIDE),PCOVS3030AWFW
232 3B ✽ A01-3758-08 SHIELD CVR(BTM),PCOVS3031AWFW
233 1B ✽ J02-1478-08 CUSHION PCUSG0045AWZZ
236 1A ✽ G01-4203-08 GND SPRING MSPRT0034AWFJ
BA ✽ N39-1415-45 SCREW(1.4X1.5) LX-BZ0040AWZZ
BB N38-2020-41 SCREW(2X2) LX-BZ0046AWZZ
BC N09-3434-08 SCREW(1.4X2.5) LX-BZ0800AFZZ
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
^
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R1524,525 R92-1824-08 JUMPER R 0 J 1/10W
R1526 RK73GB1J682J CHIP R 6.8K J 1/16W
R1527 RK73GB1J473J CHIP R 47K J 1/16W
R1528 R92-1824-08 JUMPER R 0 J 1/10W
R1529 RK73GB1J221J CHIP R 220 J 1/16W
R1530 R92-1823-08 JUMPER R 0 J 1/16W
R1532 RK73GB1J332J CHIP R 3.3K J 1/16W
R1533-536 RK73GB1J102J CHIP R 1.0K J 1/16W
R1537,538 RK73GB1J221J CHIP R 220 J 1/16W
R1539 RK73GB1J121J CHIP R 120 J 1/16W
R1540 R92-1824-08 JUMPER R 0 J 1/10W
R1600,601 RK73GB1J682J CHIP R 6.8K J 1/16W
R1605,606 ✽ R92-1949-08 CHIP R 10K F 1/16W
R1612 ✽ R92-1950-08 CHIP R 150K F 1/16W
R1614 ✽ R92-1947-08 CHIP R 100K F 1/16W
R1616,617 RK73GB1J103J CHIP R 10K J 1/16W
R1618 RK73GB1J153J CHIP R 15K J 1/16W
R1620 RK73GB1J153J CHIP R 15K J 1/16W
R1621 RK73GB1J682J CHIP R 6.8K J 1/16W
R1622,623 RK73GB1J223J CHIP R 22K J 1/16W
R1624 RK73GB1J682J CHIP R 6.8K J 1/16W
R1701 RK73GB1J393J CHIP R 39K J 1/16W
R1702 RK73GB1J303J CHIP R 30K J 1/16W
R1703 ✽ R92-1951-08 CHIP R 1K F 1/16W
R1704 RK73GB1J332J CHIP R 3.3K J 1/16W
R1705 RK73GB1J821J CHIP R 820 J 1/16W
R1707 RK73GB1J105J CHIP R 1.0M J 1/16W
R1708 RK73GB1J102J CHIP R 1.0K J 1/16W
R1710 RK73GB1J684J CHIP R 680K J 1/16W
R1711 RK73FB2A120J CHIP R 12 J 1/10W
R1712 RK73GB1J273J CHIP R 27K J 1/16W
R1714 RK73FB2A120J CHIP R 12 J 1/10W
R1716 RK73GB1J104J CHIP R 100K J 1/16W
R1801 RK73GB1J271J CHIP R 270 J 1/16W
R1802 ✽ R92-1952-08 56K F 1/16W
R1803 ✽ R92-1953-08 CHIP R 33K F 1/16W
R1804 RK73GB1J391J CHIP R 390 J 1/16W
R1805 RK73GB1J271J CHIP R 270 J 1/16W
R1806 RK73EB2B1R0J CHIP R 1.0 J 1/8W
R1807 RK73GB1J273J CHIP R 27K J 1/16W
R1808 RK73GB1J182J CHIP R 1.8K J 1/16W
R1809 RK73EB2B1R0J CHIP R 1.0 J 1/8W
R1811 RK73EB2B1R0J CHIP R 1.0 J 1/8W
R1930 RK73FB2A391J CHIP R 390 J 1/10W
R1931 RK73FB2A561J CHIP R 560 J 1/10W
R1932 RK73FB2A121J CHIP R 120 J 1/10W
R1933 RK73FB2A271J CHIP R 270 J 1/10W
SW1930 ✽ S68-0126-08 PUSH SWITCH
SW1931 ✽ S68-0127-08 PUSH SWITCH
SW1932-34 ✽ S64-0049-08 LEVER SWITCH
SW1936 ✽ S64-0050-08 LEVER SWITCH
D1300 SBE803 DIODE
D1401 SB00703Q DIODE
D1402 1SS355 DIODE
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
%
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
MD MECHANISM (D40-1656-05) MDM-99A

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
