Kenwood MDX-F1 Service Manual

MDX-F1
46
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
L1701,702 L90-0099-08 COIL
LX1201 L77-2224-08 CRYSTAL RESONATOR
R1100 RK73EB2B270J CHIP R 27 J 1/8W
R1101 RK73GB1J1R0J CHIP R 1.0 J 1/16W
R1102 RK73GB1J103J CHIP R 10K J 1/16W
R1103 RK73GB1J394J CHIP R 390K J 1/16W
R1105 RK73GB1J122J CHIP R 1.2K J 1/16W
R1106 RK73GB1J563J CHIP R 56K J 1/16W
R1107 RK73GB1J561J CHIP R 560 J 1/16W
R1108-112 RK73GB1J223J CHIP R 22K J 1/16W
R1200,201 ✽ R92-1947-08 CHIP R 100K F 1/16W
R1202,203 ✽ R92-1948-08 CHIP R 120K F 1/16W
R1204,205 RK73GB1J823J CHIP R 82K J 1/16W
R1206,207 RK73GB1J623J CHIP R 62K J 1/16W
R1208 RK73GB1J221J CHIP R 220 J 1/16W
R1209 RK73GB1J101J CHIP R 100 J 1/16W
R1210,211 RK73GB1J221J CHIP R 220 J 1/16W
R1212 RK73GB1J470J CHIP R 47 J 1/16W
R1214 RK73GB1J103J CHIP R 10K J 1/16W
R1215 RK73GB1J105J CHIP R 1.0M J 1/16W
R1217 RK73GB1J151J CHIP R 150 J 1/16W
R1219 RK73GB1J103J CHIP R 10K J 1/16W
R1221,222 RK73GB1J103J CHIP R 10K J 1/16W
R1300 RK73FB2A8R2J CHIP R 8.2 J 1/10W
R1301 RK73GB1J100J CHIP R 10 J 1/16W
R1304 RK73FB2A151J CHIP R 150 J 1/10W
R1401 RK73GB1J272J CHIP R 2.7K J 1/16W
R1403 RK73GB1J471J CHIP R 470 J 1/16W
R1405 RK73GB1J104J CHIP R 100K J 1/16W
R1406 RK73GB1J103J CHIP R 10K J 1/16W
R1407,408 RK73GB1J332J CHIP R 3.3K J 1/16W
R1409 R92-1823-08 JUMPER R 0 J 1/16W
R1414 RK73GB1J224J CHIP R 220K J 1/16W
R1415 RK73GB1J102J CHIP R 1.0K J 1/16W
R1417,418 RK73GB1J102J CHIP R 1.0K J 1/16W
R1420 RK73GB1J102J CHIP R 1.0K J 1/16W
R1424 RK73GB1J473J CHIP R 47K J 1/16W
R1430 RK73GB1J103J CHIP R 10K J 1/16W
R1435 RK73GB1J103J CHIP R 10K J 1/16W
R1441 RK73GB1J473J CHIP R 47K J 1/16W
R1443 RK73GB1J102J CHIP R 1.0K J 1/16W
R1444 RK73GB1J103J CHIP R 10K J 1/16W
R1460,461 RK73GB1J103J CHIP R 10K J 1/16W
R1462 R92-1823-08 JUMPER R 0 J 1/16W
R1463 RK73GB1J103J CHIP R 10K J 1/16W
R1510 RK73GB1J102J CHIP R 1.0K J 1/16W
R1511 RK73GB1J822J CHIP R 8.2K J 1/16W
R1512 RK73FB2A470J CHIP R 47 J 1/10W
R1513 RK73GB1J822J CHIP R 8.2K J 1/16W
R1515,516 RK73GB1J182J CHIP R 1.8K J 1/16W
R1517,518 RK73GB1J470J CHIP R 47 J 1/16W
R1520 RK73GB1J473J CHIP R 47K J 1/16W
R1521 RK73GB1J121J CHIP R 120 J 1/16W
R1523 RK73GB1J473J CHIP R 47K J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
$
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C1506 CC73GCH1H101J CHIP C 100PF J
C1507 CK73GB1C473K CHIP C 0.047UF K
C1509 CC73GCH1H101J CHIP C 100PF J
C1510 CC73GCH1H221J CHIP C 220PF J
C1512 CC73GCH1H221J CHIP C 220PF J
C1601-604 CC73GSL1H821J CHIP C 820PF J
C1606 C92-0172-08 CHIP-C 10UF K
C1607 CK73FF1C105Z CHIP C 1.0UF Z
C1610 C92-0171-08 CHIP-C 4.7UF K
C1611,612 CK73GB1H562K CHIP C 5600PF K
C1613 CK73GB1E153K CHIP C 0.015UF K
C1615 CK73GB1E153K CHIP C 0.015UF K
C1616 C92-0151-08 ELECTRO 100UF 10WV
C1619 C93-0044-08 CERAMIC 330PF J
C1655 CK73GB1E153K CHIP C 0.015UF K
C1700,701 C92-0162-08 ELECTRO 47UF 4WV
C1702 CK73GB1H102K CHIP C 1000PF K
C1703 CK73GF1E104Z CHIP C 0.10UF Z
C1704 C92-0162-08 ELECTRO 47UF 4WV
C1705 CK73GF1E104Z CHIP C 0.10UF Z
C1706 CK73FF1H103Z CHIP C 0.010UF Z
C1707 CK73FF1C105Z CHIP C 1.0UF Z
C1708,709 CK73FF1H103Z CHIP C 0.010UF Z
C1710 C92-0173-08 ELECTRO 10UF 16WV
C1711 C92-0162-08 ELECTRO 47UF 4WV
C1712 C92-0173-08 ELECTRO 10UF 16WV
C1713 CK73FF1H103Z CHIP C 0.010UF Z
C1714 CK73FF1C105Z CHIP C 1.0UF Z
C1715 CK73FB1C104K CHIP C 0.10UF K
C1716 C92-0162-08 ELECTRO 47UF 4WV
C1741 CC73GSL1H821J CHIP C 820PF J
C1750 CC73GSL1H821J CHIP C 820PF J
C1800 C92-0174-08 ELECTRO 220UF 4WV
C1801,802 C92-0172-08 CHIP-C 10UF K
C1803 C92-0151-08 ELECTRO 100UF 10WV
C1804 CK73EF1C225Z CHIP C 2.2UF Z
C1805 CK73FF1C105Z CHIP C 1.0UF Z
CN1101 ✽ E40-8618-08 FLAT CABLE CONNECTOR,28P
CN1300 ✽ E40-8619-08 PIN ASSY 2P
CN1401 E40-8211-08 FLAT CABLE CONNECTOR,5P
CN1402 ✽ E40-8620-08 FLAT CABLE CONNECTOR,6P
CN1501 E40-8371-08 FLAT CABLE CONNECTOR,28P
CN1931 E40-8211-08 FLAT CABLE CONNECTOR
CN1932 ✽ E40-8617-08 FLAT CABLE CONNECTOR
PCB-E 3A ✽ J70-1414-08 PC BOARD
L1100 L90-0100-08 COIL
L1101 L90-0099-08 COIL
L1200 L90-0301-08 COIL
L1201 L90-0100-08 COIL
L1300 L90-0322-08 COIL
L1501 L90-0303-08 COIL
L1502 L90-0301-08 COIL
L1600 L90-0303-08 COIL
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
#
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
