Kenwood MDX-F1 Service Manual

MDX-F1
45
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
Q418,419 2SC1845(F,E) TRANSISTOR
Q501 HN1C01F DUAL TRANSISTOR
Q503 HN1C01F DUAL TRANSISTOR
Q505 2SC4081(R,S) TRANSISTOR
Q505 2SD1819A(Q,R) TRANSISTOR
Q509 2SC4081(R,S) TRANSISTOR
Q509 2SD1819A(Q,R) TRANSISTOR
Q601 2SC4081(R,S) TRANSISTOR
Q601 2SD1819A(Q,R) TRANSISTOR
Q602 2SC2003(L,K) TRANSISTOR
A151 ✽ W02-2739-05 TUNER ASSY
A501 ✽ W02-2718-05 ELECTRIC CIRCUIT MODULE
C1100 C92-0171-08 CHIP-C 4.7UF K
C1101 C93-0033-08 CERAMIC 1UF K
C1102 CK73FF1C105Z CHIP C 1.0UF Z
C1103 CK73FB1H273K CHIP C 0.027UF K
C1104 CK73FB1H333K CHIP C 0.033UF K
C1105 CK73GB1H332K CHIP C 3300PF K
C1106 C93-0033-08 CERAMIC 1UF K
C1107 CK73GB1C333K CHIP C 0.033UF K
C1108 CK73FB1C474K CHIP C 0.47UF K
C1109 C93-0033-08 CERAMIC 1UF K
C1110 CK73FB1H472K CHIP C 4700PF K
C1111 CK73FB1C474K CHIP C 0.47UF K
C1112 C93-0044-08 CERAMIC 330PF J
C1113-117 C93-0034-08 CERAMIC 270PF J
C1118 CK73FF1C105Z CHIP C 1.0UF Z
C1119 C93-0033-08 CERAMIC 1UF K
C1200 CK73FF1C105Z CHIP C 1.0UF Z
C1201 C92-0172-08 CHIP-C 10UF K
C1202,203 CK73FF1C105Z CHIP C 1.0UF Z
C1204 CK73GB1C473K CHIP C 0.047UF K
C1205 CK73FF1C105Z CHIP C 1.0UF Z
C1206 CK73GB1H122K CHIP C 1200PF K
C1207 CK73FF1C105Z CHIP C 1.0UF Z
C1208,209 CC73GCH1H120J CHIP C 12PF J
C1210 CC73GCH1H220J CHIP C 22PF J
C1300 CC73GCH1H470J CHIP C 47PF J
C1301 CK73GB1C273K CHIP C 0.027UF K
C1302 C92-0172-08 CHIP-C 10UF K
C1303 CK73FF1C105Z CHIP C 1.0UF Z
C1304 CC73FCH1H221J CHIP C 220PF J
C1402 CK73GB1C223K CHIP C 0.022UF K
C1403 CK73GF1E104Z CHIP C 0.10UF Z
C1404 CK73GB1C473K CHIP C 0.047UF K
C1405,406 CK73GB1H681K CHIP C 680PF K
C1407 CK73GB1C473K CHIP C 0.047UF K
C1409 CK73FF1C105Z CHIP C 1.0UF Z
C1411 CK73GB1C223K CHIP C 0.022UF K
C1501 CK73FF1C105Z CHIP C 1.0UF Z
C1503 CK73EB1C334K CHIP C 0.33UF K
C1505 CK73GB1C473K CHIP C 0.047UF K
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
@
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
IC301 ✽ M62498FP ANALOGUE IC
IC302 NJM4565MD IC(OP AMP X2)
IC351 BA5416 ANALOGUE IC
IC352 NJM4565MD IC(OP AMP X2)
IC401 HA12219NT ANALOGUE IC
IC402 BA3126N ANALOGUE IC
IC501 LC75710NED MOS-IC
IC601 ✽ M30622MC-746FP MI-COM IC
IC602 S-80840ANY ANALOGUE IC
IC603 TC74HCT7007AF MOS-IC
Q1 2SC4081(R,S) TRANSISTOR
Q1 2SD1819A(Q,R) TRANSISTOR
Q2 2SA1175(F,E) TRANSISTOR
Q2 2SA933AS(Q,R) TRANSISTOR
Q11 2SD2012 TRANSISTOR
Q11 2SD2061 TRANSISTOR
Q12 2SC4081(R,S) TRANSISTOR
Q12 2SD1819A(Q,R) TRANSISTOR
Q14 2SC3940A(R,S) TRANSISTOR
Q16 2SC4081(R,S) TRANSISTOR
Q16 2SD1819A(Q,R) TRANSISTOR
Q101 2SD2012 TRANSISTOR
Q101 2SD2061 TRANSISTOR
Q201 2SA1577(Q,R) TRANSISTOR
Q202 2SA1286-T11 TRANSISTOR
Q203 DTC124EUA DIGITAL TRANSISTOR
Q203 UN5212 DIGITAL TRANSISTOR
Q204 2SA1286-T11 TRANSISTOR
Q205 DTC124EUA DIGITAL TRANSISTOR
Q205 UN5212 DIGITAL TRANSISTOR
Q301 2SC3940A(R,S) TRANSISTOR
Q351,352 2SC2878(B) TRANSISTOR
Q353 DTA124EUA DIGITAL TRANSISTOR
Q353 UN5112 DIGITAL TRANSISTOR
Q354 DTA124ESA DIGITAL TRANSISTOR
Q354 UN4112 DIGITAL TRANSISTOR
Q405 DTC124EUA DIGITAL TRANSISTOR
Q405 UN5212 DIGITAL TRANSISTOR
Q406 DTA124EUA DIGITAL TRANSISTOR
Q406 UN5112 DIGITAL TRANSISTOR
Q407 DTC124EUA DIGITAL TRANSISTOR
Q407 UN5212 DIGITAL TRANSISTOR
Q408 DTA124EUA DIGITAL TRANSISTOR
Q408 UN5112 DIGITAL TRANSISTOR
Q409 2SC2003(L,K) TRANSISTOR
Q410,411 KTC3199(Y,GR) TRANSISTOR
Q410,411 2SC2785(F,E) TRANSISTOR
Q412 2SA1286-T11 TRANSISTOR
Q413 DTC124EUA DIGITAL TRANSISTOR
Q413 UN5212 DIGITAL TRANSISTOR
Q414 2SA1286-T11 TRANSISTOR
Q415,416 DTC124EUA DIGITAL TRANSISTOR
Q415,416 UN5212 DIGITAL TRANSISTOR
Q417 DTA124EUA DIGITAL TRANSISTOR
Q417 UN5112 DIGITAL TRANSISTOR
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
!
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
MD PCB

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
