Kenwood MDX-F1 Service Manual

MDX-F1
44
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
VR401,402 R32-0042-05 SEMI FIXED VARIABLE RESISTOR
W501-517 R92-0670-05 CHIP R 0 OHM
W519-522 R92-0670-05 CHIP R 0 OHM
W601-624 R92-0679-05 CHIP R 0 OHM
W626-635 R92-0679-05 CHIP R 0 OHM
K1 S76-0099-05 MAGNETIC RELAY
K1 ✽ S76-0102-05 MAGNETIC RELAY
S551-565 S70-0031-05 TACT SWITCH
S601,602 S64-0042-05 LEVER SWITCH
S566 ✽ T99-0629-05 ROTARY ENCODER
D1 S1ZB20(4072) DIODE
D2 -8 HSS104A DIODE
D2 -8 1SS133 DIODE
D10 HSS104A DIODE
D10 1SS133 DIODE
D11 D2SBA20F03 DIODE
D12 -15 S5688B DIODE
D12 -15 1T2 DIODE
D16 D2SBA20F03 DIODE
D17 HZS5.6N(B2) ZENER DIODE
D17 MTZJ5.6(B) ZENER DIODE
D18 ,19 S5688B DIODE
D18 ,19 1T2 DIODE
D20 ,21 HZS20N(B2) ZENER DIODE
D20 ,21 MTZJ20(B) ZENER DIODE
D22 -25 S5688B DIODE
D22 -25 1T2 DIODE
D26 UDZ3.9B ZENER DIODE
D27 HZS6.2N(B2) ZENER DIODE
D27 MTZJ6.2(B) ZENER DIODE
D101 UDZ5.6B ZENER DIODE
D151-155 DA204U DIODE
D201,202 MA111 DIODE
D301 UDZ5.6B ZENER DIODE
D302 DA204U DIODE
D401 HZS5.6N(B2) ZENER DIODE
D401 MTZJ5.6(B) ZENER DIODE
D403,404 HSS104A DIODE
D403,404 1SS133 DIODE
D501 HZS5.6N(B2) ZENER DIODE
D501 MTZJ5.6(B) ZENER DIODE
D502 HSS104A DIODE
D502 1SS133 DIODE
D505 HZS20N(B2) ZENER DIODE
D505 MTZJ20(B) ZENER DIODE
D601 UDZ5.6B ZENER DIODE
D602 1SS402 DIODE
D604 MA111 DIODE
ED501 ✽ 16-ST-35GNK FLUORESCENT INDICATOR TUBE
IC1 ✽ XC62HR5102P ANALOGUE IC
IC2 TA7812S ANALOGUE IC
IC201 CXA1571M ANALOGUE IC
IC202 BA5979S ANALOGUE IC
IC203 CXD2587Q MOS-IC
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
0
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R573 RK73FB2A182J CHIP R 1.8K J 1/10W
R574 RK73FB2A112J CHIP R 1.1K J 1/10W
R575 RK73FB2A751J CHIP R 750 J 1/10W
R576 RK73FB2A511J CHIP R 510 J 1/10W
R577 RK73FB2A271J CHIP R 270 J 1/10W
R578 RK73FB2A471J CHIP R 470 J 1/10W
R579 RK73FB2A271J CHIP R 270 J 1/10W
R580 RK73FB2A682J CHIP R 6.8K J 1/10W
R581 RK73FB2A473J CHIP R 47K J 1/10W
R584 RK73FB2A103J CHIP R 10K J 1/10W
R585 RK73FB2A362J CHIP R 3.6K J 1/10W
R586 RK73FB2A182J CHIP R 1.8K J 1/10W
R587 RK73FB2A112J CHIP R 1.1K J 1/10W
R588 RK73FB2A751J CHIP R 750 J 1/10W
R589 RK73FB2A511J CHIP R 510 J 1/10W
R590 RK73FB2A271J CHIP R 270 J 1/10W
R601 RK73FB2A102J CHIP R 1.0K J 1/10W
R602 RK73FB2A103J CHIP R 10K J 1/10W
R603 RK73FB2A104J CHIP R 100K J 1/10W
R604 RK73FB2A102J CHIP R 1.0K J 1/10W
R605 RK73FB2A103J CHIP R 10K J 1/10W
R606 RK73FB2A101J CHIP R 100 J 1/10W
R607 RK73FB2A1R0J CHIP R 1.0 J 1/10W
R608 RK73FB2A103J CHIP R 10K J 1/10W
R610-615 RK73FB2A101J CHIP R 100 J 1/10W
R616 RK73FB2A332J CHIP R 3.3K J 1/10W
R617 RK73FB2A472J CHIP R 4.7K J 1/10W
R618,619 RK73FB2A332J CHIP R 3.3K J 1/10W
R620 RK73FB2A102J CHIP R 1.0K J 1/10W
R621 RK73FB2A332J CHIP R 3.3K J 1/10W
R622 RK73FB2A475J CHIP R 4.7M J 1/10W
R623 RK73FB2A104J CHIP R 100K J 1/10W
R624 RK73FB2A105J CHIP R 1.0M J 1/10W
R625 RK73FB2A332J CHIP R 3.3K J 1/10W
R626 RK73FB2A102J CHIP R 1.0K J 1/10W
R627,628 RK73FB2A473J CHIP R 47K J 1/10W
R629 RK73FB2A222J CHIP R 2.2K J 1/10W
R631,632 RK73FB2A271J CHIP R 270 J 1/10W
R633-635 RK73FB2A102J CHIP R 1.0K J 1/10W
R636,637 RK73FB2A162J CHIP R 1.6K J 1/10W
R638 RK73FB2A101J CHIP R 100 J 1/10W
R639 RK73FB2A473J CHIP R 47K J 1/10W
R640,641 RK73FB2A101J CHIP R 100 J 1/10W
R642 RK73FB2A162J CHIP R 1.6K J 1/10W
R643-645 RK73FB2A332J CHIP R 3.3K J 1/10W
R646 RK73FB2A222J CHIP R 2.2K J 1/10W
R647 RK73FB2A332J CHIP R 3.3K J 1/10W
R648 RK73FB2A102J CHIP R 1.0K J 1/10W
R649-652 RK73FB2A101J CHIP R 100 J 1/10W
R654,655 RK73FB2A272J CHIP R 2.7K J 1/10W
R656,657 RK73FB2A2R2J CHIP R 2.2 J 1/10W
R658 RK73FB2A471J CHIP R 470 J 1/10W
R659 RK73FB2A472J CHIP R 4.7K J 1/10W
R660-662 RK73FB2A332J CHIP R 3.3K J 1/10W
VR201 R32-0038-05 SEMI FIXED VARIABLE RESISTOR
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
9
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
