Kenwood MDX-F1 Service Manual

MDX-F1
43
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R429 RK73FB2A100J CHIP R 10 J 1/10W
R430 RK73FB2A223J CHIP R 22K J 1/10W
R431 RK73FB2A103J CHIP R 10K J 1/10W
R432 RD14NB2E100J RD 10 J 1/4W
R434 RK73FB2A821J CHIP R 820 J 1/10W
R435 RK73FB2A622J CHIP R 6.2K J 1/10W
R436,437 RK73FB2A333J CHIP R 33K J 1/10W
R440 RD14NB2E100J RD 10 J 1/4W
R441 RD14NB2E4R7J RD 4.7 J 1/4W
R442 RK73FB2A473J CHIP R 47K J 1/10W
R443 RK73FB2A472J CHIP R 4.7K J 1/10W
R444 RK73FB2A473J CHIP R 47K J 1/10W
R445 RK73FB2A222J CHIP R 2.2K J 1/10W
R446 RK73FB2A683J CHIP R 68K J 1/10W
R447-451 RK73FB2A472J CHIP R 4.7K J 1/10W
R452-456 RK73FB2A101J CHIP R 100 J 1/10W
R457 RK73FB2A102J CHIP R 1.0K J 1/10W
R458,459 RK73FB2A562J CHIP R 5.6K J 1/10W
R501 RK73EB2B100J CHIP R 10 J 1/8W
R504 RK73FB2A103J CHIP R 10K J 1/10W
R505 RK73FB2A102J CHIP R 1.0K J 1/10W
R506 RK73FB2A101J CHIP R 100 J 1/10W
R509 RK73FB2A473J CHIP R 47K J 1/10W
R510 RK73EB2B473J CHIP R 47K J 1/8W
R511-514 RK73FB2A473J CHIP R 47K J 1/10W
R516,517 RK73FB2A473J CHIP R 47K J 1/10W
R518 RK73EB2B473J CHIP R 47K J 1/8W
R519,520 RK73FB2A473J CHIP R 47K J 1/10W
R521 RK73EB2B473J CHIP R 47K J 1/8W
R522,523 RK73FB2A473J CHIP R 47K J 1/10W
R524 RK73EB2B473J CHIP R 47K J 1/8W
R525 RK73FB2A473J CHIP R 47K J 1/10W
R526 RK73EB2B473J CHIP R 47K J 1/8W
R527,528 RK73FB2A473J CHIP R 47K J 1/10W
R529 RK73EB2B473J CHIP R 47K J 1/8W
R530,531 RK73FB2A473J CHIP R 47K J 1/10W
R532 RK73EB2B473J CHIP R 47K J 1/8W
R534 RK73FB2A473J CHIP R 47K J 1/10W
R535,536 RK73EB2B473J CHIP R 47K J 1/8W
R537,538 RK73FB2A473J CHIP R 47K J 1/10W
R539 RK73EB2B473J CHIP R 47K J 1/8W
R540-545 RK73FB2A473J CHIP R 47K J 1/10W
R547-551 RK73FB2A102J CHIP R 1.0K J 1/10W
R552,553 RK73FB2A223J CHIP R 22K J 1/10W
R554 RK73EB2B223J CHIP R 22K J 1/8W
R555,556 RK73FB2A223J CHIP R 22K J 1/10W
R557 RK73EB2B223J CHIP R 22K J 1/8W
R558,559 RK73FB2A223J CHIP R 22K J 1/10W
R560 RK73EB2B223J CHIP R 22K J 1/8W
R561-565 RK73FB2A223J CHIP R 22K J 1/10W
R566 RK73EB2B223J CHIP R 22K J 1/8W
R567 RK73FB2A223J CHIP R 22K J 1/10W
R569 RK73FB2A1R8J CHIP R 1.8 J 1/10W
R570,571 RK73FB2A103J CHIP R 10K J 1/10W
R572 RK73FB2A362J CHIP R 3.6K J 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
8
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R238 RK73FB2A105J CHIP R 1.0M J 1/10W
R239 RK73FB2A103J CHIP R 10K J 1/10W
R240,241 RK73FB2A332J CHIP R 3.3K J 1/10W
R242 RK73FB2A681J CHIP R 680 J 1/10W
R243 RK73FB2A152J CHIP R 1.5K J 1/10W
R244 RK73FB2A1R0J CHIP R 1.0 J 1/10W
R245,246 RK73FB2A103J CHIP R 10K J 1/10W
R247-250 RK73FB2A822J CHIP R 8.2K J 1/10W
R251,252 RK73FB2A100J CHIP R 10 J 1/10W
R254 RK73FB2A390J CHIP R 39 J 1/10W
R255 RK73FB2A473J CHIP R 47K J 1/10W
R256 RK73FB2A102J CHIP R 1.0K J 1/10W
R257 RK73FB2A473J CHIP R 47K J 1/10W
R258 RK73FB2A8R2J CHIP R 8.2 J 1/10W
R260 RK73FB2A105J CHIP R 1.0M J 1/10W
R261 RK73FB2A393J CHIP R 39K J 1/10W
R262,263 RK73FB2A101J CHIP R 100 J 1/10W
R301,302 RK73FB2A682J CHIP R 6.8K J 1/10W
R303,304 RK73FB2A123J CHIP R 12K J 1/10W
R305,306 RK73FB2A103J CHIP R 10K J 1/10W
R307,308 RK73FB2A104J CHIP R 100K J 1/10W
R309,310 RK73FB2A332J CHIP R 3.3K J 1/10W
R311,312 RK73FB2A103J CHIP R 10K J 1/10W
R313 RK73FB2A100J CHIP R 10 J 1/10W
R314 RK73FB2A102J CHIP R 1.0K J 1/10W
R315 RD14NB2E4R7J RD 4.7 J 1/4W
R317,318 RK73EB2B241J CHIP R 240 J 1/8W
R319,320 RK73FB2A102J CHIP R 1.0K J 1/10W
R323,324 RK73FB2A682J CHIP R 6.8K J 1/10W
R351,352 RK73FB2A102J CHIP R 1.0K J 1/10W
R353,354 RK73FB2A222J CHIP R 2.2K J 1/10W
R357,358 RK73FB2A471J CHIP R 470 J 1/10W
R359,360 RK73FB2A681J CHIP R 680 J 1/10W
R363,364 RK73FB2A511J CHIP R 510 J 1/10W
R365,366 RK73FB2A221J CHIP R 220 J 1/10W
R367,368 RK73FB2A220J CHIP R 22 J 1/10W
R369,370 RK73FB2A473J CHIP R 47K J 1/10W
R371,372 RK73FB2A102J CHIP R 1.0K J 1/10W
R373-376 RK73FB2A103J CHIP R 10K J 1/10W
R377 RK73FB2A222J CHIP R 2.2K J 1/10W
R379 RK73FB2A563J CHIP R 56K J 1/10W
R401,402 RK73FB2A334J CHIP R 330K J 1/10W
R403,404 RK73FB2A270J CHIP R 27 J 1/10W
R405,406 RK73FB2A223J CHIP R 22K J 1/10W
R407,408 RK73FB2A153J CHIP R 15K J 1/10W
R409,410 RK73FB2A222J CHIP R 2.2K J 1/10W
R411,412 RK73FB2A682J CHIP R 6.8K J 1/10W
R413,414 RK73FB2A272J CHIP R 2.7K J 1/10W
R415,416 RK73FB2A154J CHIP R 150K J 1/10W
R417,418 RK73FB2A103J CHIP R 10K J 1/10W
R419,420 RK73FB2A153J CHIP R 15K J 1/10W
R421 RK73FB2A822J CHIP R 8.2K J 1/10W
R422 RK73FB2A392J CHIP R 3.9K J 1/10W
R423,424 RK73FB2A473J CHIP R 47K J 1/10W
R427 RD14NB2E330J RD 33 J 1/4W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
7
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
