Kenwood MDX-F1 Service Manual

MDX-F1
42
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
T1 ✽ L07-2858-05 POWER TRANSFORMER
X201 L77-2190-05 CRYSTAL RESONATOR(16.9344MHZ)
X601 L78-0294-05 RESONATOR (10.000M)
X602 L77-2173-05 CRYSTAL RESONATOR(32.768KHZ)
R2 RK73FB2A104J CHIP R 100K J 1/10W
R3 RK73FB2A472J CHIP R 4.7K J 1/10W
R4 RK73FB2A473J CHIP R 47K J 1/10W
R8 RK73FB2A105J CHIP R 1.0M J 1/10W
R9 RK73FB2A334J CHIP R 330K J 1/10W
R11 RK73FB2A104J CHIP R 100K J 1/10W
R12 RK73FB2A183J CHIP R 18K J 1/10W
R13 RK73FB2A104J CHIP R 100K J 1/10W
R14 RK73FB2A103J CHIP R 10K J 1/10W
R15 RK73FB2A471J CHIP R 470 J 1/10W
R16 RK73FB2A100J CHIP R 10 J 1/10W
R17 RK73FB2A104J CHIP R 100K J 1/10W
R18 RK73FB2A333J CHIP R 33K J 1/10W
R19 RK73FB2A103J CHIP R 10K J 1/10W
R20 RK73FB2A102J CHIP R 1.0K J 1/10W
R21 RD14NB2E4R7J RD 4.7 J 1/4W
R101 RK73FB2A471J CHIP R 470 J 1/10W
R102 RK73FB2A100J CHIP R 10 J 1/10W
R104 RD14NB2E3R3J RD 3.3 J 1/4W
R151,152 RK73FB2A222J CHIP R 2.2K J 1/10W
R153,154 RK73FB2A103J CHIP R 10K J 1/10W
R155-159 RK73FB2A102J CHIP R 1.0K J 1/10W
R160 RK73FB2A101J CHIP R 100 J 1/10W
R201-204 RK73FB2A473J CHIP R 47K J 1/10W
R205,206 RK73FB2A154J CHIP R 150K J 1/10W
R207 RK73FB2A1R0J CHIP R 1.0 J 1/10W
R208 RK73FB2A473J CHIP R 47K J 1/10W
R209 RK73FB2A100J CHIP R 10 J 1/10W
R210 RK73FB2A332J CHIP R 3.3K J 1/10W
R211 RK73FB2A822J CHIP R 8.2K J 1/10W
R212 RK73EB2B472J CHIP R 4.7K J 1/8W
R213 RK73FB2A473J CHIP R 47K J 1/10W
R215,216 RK73FB2A103J CHIP R 10K J 1/10W
R218 RK73FB2A153J CHIP R 15K J 1/10W
R219 RK73FB2A273J CHIP R 27K J 1/10W
R220 RK73FB2A2R2J CHIP R 2.2 J 1/10W
R221 RK73FB2A224J CHIP R 220K J 1/10W
R222,223 RK73FB2A105J CHIP R 1.0M J 1/10W
R224 RK73FB2A224J CHIP R 220K J 1/10W
R225 RK73FB2A102J CHIP R 1.0K J 1/10W
R226 RK73FB2A331J CHIP R 330 J 1/10W
R227 RK73FB2A103J CHIP R 10K J 1/10W
R228 RK73FB2A184J CHIP R 180K J 1/10W
R229 RK73FB2A682J CHIP R 6.8K J 1/10W
R230,231 RK73FB2A472J CHIP R 4.7K J 1/10W
R232,233 RK73FB2A153J CHIP R 15K J 1/10W
R234 RK73FB2A104J CHIP R 100K J 1/10W
R235 RK73FB2A472J CHIP R 4.7K J 1/10W
R236 RK73FB2A333J CHIP R 33K J 1/10W
R237 RK73FB2A104J CHIP R 100K J 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
6
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C604,605 CE04KW1A101M ELECTRO 100UF 10WV
C606-610 CK73FB1H103K CHIP C 0.010UF K
C611 CK73EB1H103K CHIP C 0.010UF K
C612,613 CK73FB1H103K CHIP C 0.010UF K
C614 CC73FCH1H180J CHIP C 18PF J
C615 CC73FCH1H220J CHIP C 22PF J
C616 CK73FF1C105Z CHIP C 1.0UF Z
C617 CK73FB1H102K CHIP C 1000PF K
C618 CK73FB1H103K CHIP C 0.010UF K
C619-622 CC73FCH1H470J CHIP C 47PF J
C624 CE04KW1E470M ELECTRO 47UF 25WV
C625 CK73FB1H103K CHIP C 0.010UF K
C628 CK73FB1H103K CHIP C 0.010UF K
C629 CC73FCH1H101J CHIP C 100PF J
C630 CC73ESL1H101J CHIP C 100PF J
C631 CK73FF1E104Z CHIP C 0.10UF Z
C632 CK73FB1H103K CHIP C 0.010UF K
C633 CK73FB1H471K CHIP C 470PF K
C634 CK73FF1C105Z CHIP C 1.0UF Z
CN1 E40-3254-05 PIN ASSY
CN2 E40-3259-05 PIN ASSY
CN3 E40-3251-05 PIN ASSY
CN4 ✽ E40-8609-05 FLAT CABLE CONNECTOR
CN5 E40-8328-05 FLAT CABLE CONNECTOR
CN6 E40-3250-05 PIN ASSY
CN7 E40-3248-05 PIN ASSY
CN8 E40-8326-05 FLAT CABLE CONNECTOR
CN9 ✽ E40-8480-05 FLAT CABLE CONNECTOR
CN10 ✽ E40-8476-05 FLAT CABLE CONNECTOR
CN11 ✽ E40-8477-05 FLAT CABLE CONNECTOR
CN13 E40-3237-05 PIN ASSY
CN14 ✽ E40-8587-05 PIN ASSY
CN15 E40-3246-05 PIN ASSY
CN101 E40-4872-05 PIN ASSY
CN501 ✽ E40-8500-05 FLAT CABLE CONNECTOR
CN502 ✽ E40-8495-05 FLAT CABLE CONNECTOR
CN503 ✽ E40-8497-05 FLAT CABLE CONNECTOR
J151 E70-0051-05 LOCK TERMINAL BOARD
J301 E11-0399-05 MINIATURE PHONE JACK(7P)
J351 ✽ E03-0367-05 AC INLET
E5 -9 J11-0808-05 WIRE CLAMPER
E501 J19-6038-03 HOLDER
L101 L92-0089-05 CHIP FERRITE
L103 L92-0089-05 CHIP FERRITE
L151 L40-1001-17 SMALL FIXED INDUCTOR(10UH,K)
L152 L79-1216-05 LINE FILTER
L201 L40-1001-17 SMALL FIXED INDUCTOR(10UH,K)
L203 L79-1216-05 LINE FILTER
L204 ✽ L92-0507-05 CHIP FERRITE
L401,402 L40-1035-20 SMALL FIXED INDUCTOR(10MH,J)
L403 ✽ L32-1023-05 BIAS OSCILLATING COIL
L404 L40-1001-17 SMALL FIXED INDUCTOR(10UH,K)
L601 L40-1001-17 SMALL FIXED INDUCTOR(10UH,K)
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
5
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
