Kenwood MDX-F1 Service Manual

MDX-F1
41
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C341-346 CC73FCH1H470J CHIP C 47PF J
C347,348 CC73FCH1H221J CHIP C 220PF J
C349,350 CK73FB1C104K CHIP C 0.10UF K
C353,354 CC73FCH1H221J CHIP C 220PF J
C355,356 CE04KW1A221M ELECTRO 220UF 10WV
C357,358 CE04KW1E470M ELECTRO 47UF 25WV
C359,360 CK73FF1E104Z CHIP C 0.10UF Z
C361,362 CE04KW1E222M ELECTRO 2200UF 25WV
C363 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C364 CE04DW1E331M ELECTRO 330UF 25WV
C367,368 CK73FB1H472K CHIP C 4700PF K
C369,370 CE04KW1H3R3M ELECTRO 3.3UF 50WV
C371 CE04KW1A221M ELECTRO 220UF 10WV
C375 CK73FB1H102K CHIP C 1000PF K
C376 CK73EB1H473K CHIP C 0.047UF K
C401,402 CE04KW1H010M ELECTRO 1.0UF 50WV
C403,404 CK73FB1H103K CHIP C 0.010UF K
C405,406 CE04KW1A221M ELECTRO 220UF 10WV
C407,408 CE04KW1H2R2M ELECTRO 2.2UF 50WV
C409,410 CE04KW1H100M ELECTRO 10UF 50WV
C411,412 CK73FB1H561K CHIP C 560PF K
C413-416 CC45FSL1H221J CERAMIC 220PF J
C417 CE04KW1E470M ELECTRO 47UF 25WV
C418 CE04KW1A101M ELECTRO 100UF 10WV
C419,420 CE04KW1H100M ELECTRO 10UF 50WV
C421 CK73FB1C104K CHIP C 0.10UF K
C422 CE04KW1H330M ELECTRO 33UF 50WV
C424,425 CK73FB1H103K CHIP C 0.010UF K
C426 CK73FB1H153KTA CHIP C 0.015UF K
C427 CE04KW1E101M ELECTRO 100UF 25WV
C428 CQ93HP2A682J MYLAR 6800PF J
C429 CE04KW1C331M ELECTRO 330UF 16WV
C430 CK73FB1H103K CHIP C 0.010UF K
C431 CK45FB2H471K CERAMIC 470PF K
C432 CK73EB1H103K CHIP C 0.010UF K
C501 CE04RW1C220M ELECTRO 22UF 16WV
C502 ✽ C90-3895-05 ELECTRO 1UF 50WV
C503 CE04KW1H010M ELECTRO 1.0UF 50WV
C504 ✽ C90-3896-05 ELECTRO 47UF 25WV
C505 ✽ C90-3897-05 ELECTRO 22UF 50WV
C506 CC73FCH1H680J CHIP C 68PF J
C507 CK73FB1H223K CHIP C 0.022UF K
C508 CK73FB1H102K CHIP C 1000PF K
C509,510 CC73FCH1H470J CHIP C 47PF J
C551,552 CC73FCH1H101J CHIP C 100PF J
C566 CC73FCH1H101J CHIP C 100PF J
C568 CC73FCH1H101J CHIP C 100PF J
C577 CC73FCH1H101J CHIP C 100PF J
C578 CC73FCH1H221J CHIP C 220PF J
C582 CC73ESL1H101J CHIP C 100PF J
C583 CC73FCH1H221J CHIP C 220PF J
C584 CC73FCH1H471J CHIP C 470PF J
C601 CE04KW1H2R2M ELECTRO 2.2UF 50WV
C602 CK73FF1C105Z CHIP C 1.0UF Z
C603 CE04DW0J102M ELECTRO 1000UF 6.3WV
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
4
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C202 CK73FF1C105Z CHIP C 1.0UF Z
C203,204 CE04KW1A101M ELECTRO 100UF 10WV
C205 CC73FCH1H270J CHIP C 27PF J
C206 CE04KW1A221M ELECTRO 220UF 10WV
C207 CK73FB1H473K CHIP C 0.047UF K
C208 CE04KW1H100M ELECTRO 10UF 50WV
C209 CK73FB1H102K CHIP C 1000PF K
C210 CK73FF1E104Z CHIP C 0.10UF Z
C211 CK73FB1H333K CHIP C 0.033UF K
C212 CE04KW1A101M ELECTRO 100UF 10WV
C213 CC73FCH1H221J CHIP C 220PF J
C214 CC73FCH1H181J CHIP C 180PF J
C215 CK73FB1H223K CHIP C 0.022UF K
C216 CK73FB1C104K CHIP C 0.10UF K
C217 CK73FB1H103K CHIP C 0.010UF K
C218 CK73FB1H332K CHIP C 3300PF K
C219 CK73FB1H152K CHIP C 1500PF K
C220 CK73FB1H473K CHIP C 0.047UF K
C221 CK73FF1C105Z CHIP C 1.0UF Z
C222 CE04RW0J331M ELECTRO 330UF 6.3WV
C223,224 CK73FB1H152K CHIP C 1500PF K
C225,226 CK73FB1H271K CHIP C 270PF K
C227 CK73FF1E104Z CHIP C 0.10UF Z
C228 CC73FCH1H470J CHIP C 47PF J
C229 CE04KW1E470M ELECTRO 47UF 25WV
C230,231 CC73FCH1H470J CHIP C 47PF J
C232 CK73FB1H103K CHIP C 0.010UF K
C235,236 CC73FCH1H470J CHIP C 47PF J
C237 CC73FCH1H331J CHIP C 330PF J
C238 CK73FB1H102K CHIP C 1000PF K
C239 CK73EB1H103K CHIP C 0.010UF K
C240,241 CK73EF1C105Z CHIP C 1.0UF Z
C242 CK73FF1E104Z CHIP C 0.10UF Z
C243 CK73EB1H103K CHIP C 0.010UF K
C244 CK73EF1C105Z CHIP C 1.0UF Z
C245 CC73FCH1H150J CHIP C 15PF J
C301,302 CE04KW1H010M ELECTRO 1.0UF 50WV
C303,304 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C305,306 CK73FB1C104K CHIP C 0.10UF K
C307-310 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C311,312 CE04KW1H100M ELECTRO 10UF 50WV
C313,314 CK73FB1C104K CHIP C 0.10UF K
C315-318 CK73FB1C154K CHIP C 0.15UF K
C319,320 CK73FB1H472K CHIP C 4700PF K
C321,322 CE04KW1H2R2M ELECTRO 2.2UF 50WV
C323-326 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C327 CE04KW1H100M ELECTRO 10UF 50WV
C328 C90-3816-05 ELECTRO 10UF 35WV
C329,330 CC73FCH1H221J CHIP C 220PF J
C331 CE04KW1H100M ELECTRO 10UF 50WV
C332 CE04KW1E470M ELECTRO 47UF 25WV
C333 CK73FB1H103K CHIP C 0.010UF K
C334 CE04KW1E470M ELECTRO 47UF 25WV
C335,336 CC73FCH1H102J CHIP C 1000PF J
C337-340 CC73FCH1H221J CHIP C 220PF J
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
3
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
