Kenwood MDX-F1 Service Manual

MDX-F1
9
CIRCUIT DESCRIPTION
7-4 Key Operation in Test Mode
7-4-1 Tuner Mode
7-4-2 CD Mode
Key Display Descriptions
STOP Normal mode Select the receiving mode of AUTO(STEREO) or MANUAL(MONO)
SOUND Normal mode Select the preset memory by ten step.
î10î20î30î40î00(--)î
MD REC TUNING DOWN/UP
TAPE REC Normal mode
SKIP DOWN P.CH DOWN/UP
SKIP UP Normal mode
SET/DEMO A MUTE ONîMUTE ON Mute operation works alternately: îAUDI0 MUTE
îMUTE OFFîîMUTE ONîMUTE OFFî
Key Display Descriptions
CD PLAY 05 - - : - - TRACKING-SERVO:ON
03 - - : - - TRACKING-SERVO:OFF
01 - - : - - Stop to operation
07 TB value/ FB value Both TB and FB values
STOP* 08 TG value/ FG value Both TG and FG values
09 FE value/ RF value Both FE and RF values
10 TE value /VC value Both TE and VC values
SKIP UP EX : 01~02 CD's track up operation
MD REC Time CD's FF operation. Feed the pickup outwards at STOP mode
SKIP DOWN EX : 02~01 CD's track down operation
TAPE REC Time CD's FB operation. Feed the pickup inwards at STOP mode.
*Value shows self-adjustment result and hex.
7-4-3 MD Mode
Key Display Descriptions
STOP 01 - - : - - Stop the MD operation. Muting is off.
SOUND
DIGITAL In STOP mode, select the input of recording
ANALOG In STOP mode, select the input of recording
SKIP UP EX : 01~02 MD's track up operation
SKIP DOWN EX : 02~01 MD's track down operation
SET ALL ERASE Stop the MD operation. Start operation of ALL-ERASE if disc is recordable.
REPEAT Normal mode One Touch Edit operation starts.

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
