TK-3170
9
PARTS LIST
R623 RK73EB2ER39K CHIP R 0.39 K 1/4W
R624 RK73HB1J104J CHIP R 100K J 1/16W
R625 RK73HB1J680J CHIP R 68 J 1/16W
R627 RK73HB1J223J CHIP R 22K J 1/16W
R628 RK73HB1J183J CHIP R 18K J 1/16W
R629 RK73EB2ER39K CHIP R 0.39 K 1/4W
R630,631 RK73HH1J154D CHIP R 150K D 1/16W
R632,633 RK73HH1J334D CHIP R 330K D 1/16W
R634 RK73HB1J103J CHIP R 10K J 1/16W
R635 RK73HB1J473J CHIP R 47K J 1/16W
R636 R92-1368-05 CHIP R 0 OHM
R637 RK73HB1J223J CHIP R 22K J 1/16W
R638 RK73HB1J474J CHIP R 470K J 1/16W
R639 RK73HB1J184J CHIP R 180K J 1/16W
R640 RK73HB1J474J CHIP R 470K J 1/16W
R641 R92-1252-05 CHIP R 0 OHM J 1/16W
R642 RK73HB1J220J CHIP R 22 J 1/16W
R643 RK73HB1J683J CHIP R 68K J 1/16W
R645,646 RK73GB1J271J CHIP R 270 J 1/16W
R647 R92-1252-05 CHIP R 0 OHM J 1/16W
R648 RK73HB1J5R6J CHIP R 5.6 J 1/16W
R649 RK73HB1J473J CHIP R 47K J 1/16W
R701 RK73HB1J103J CHIP R 10K J 1/16W
R702,703 RK73HB1J472J CHIP R 4.7K J 1/16W
R704 RK73HB1J224J CHIP R 220K J 1/16W
R705,706 RK73HB1J472J CHIP R 4.7K J 1/16W
R707 RK73HB1J101J CHIP R 100 J 1/16W
R708 RK73HB1J103J CHIP R 10K J 1/16W
R710 RK73HB1J102J CHIP R 1.0K J 1/16W
R711 RK73HB1J474J CHIP R 470K J 1/16W
R713 RK73HB1J334J CHIP R 330K J 1/16W
R715,716 RK73HB1J332J CHIP R 3.3K J 1/16W
R717 RK73HB1J272J CHIP R 2.7K J 1/16W
R718 RK73HB1J100J CHIP R 10 J 1/16W
R719 RK73HB1J332J CHIP R 3.3K J 1/16W
R721 RK73HB1J224J CHIP R 220K J 1/16W
R722 RK73HB1J101J CHIP R 100 J 1/16W
R726 RK73HB1J474J CHIP R 470K J 1/16W
R727 RK73HB1J681J CHIP R 680 J 1/16W
R728 RK73HB1J101J CHIP R 100 J 1/16W
R729 RK73HB1J470J CHIP R 47 J 1/16W
R730 RK73HB1J472J CHIP R 4.7K J 1/16W
R732 RK73HB1J391J CHIP R 390 J 1/16W
R733 R92-1368-05 CHIP R 0 OHM
R734 RK73HB1J563J CHIP R 56K J 1/16W
R735 RK73HB1J104J CHIP R 100K J 1/16W
R736 RK73HB1J563J CHIP R 56K J 1/16W
R737 RK73HB1J104J CHIP R 100K J 1/16W
R738 RK73HB1J180J CHIP R 18 J 1/16W
R739-741 RK73HB1J105J CHIP R 1.0M J 1/16W
R743 RK73HB1J220J CHIP R 22 J 1/16W
R744 RK73HB1J221J CHIP R 220 J 1/16W
R747 RK73HB1J104J CHIP R 100K J 1/16W
R748 RK73HB1J824J CHIP R 820K J 1/16W
R750,751 RK73HB1J104J CHIP R 100K J 1/16W
R753 R92-1368-05 CHIP R 0 OHM
R754,755 RK73HB1J105J CHIP R 1.0M J 1/16W
R756 R92-0670-05 CHIP R 0 OHM
R757 RK73HB1J105J CHIP R 1.0M J 1/16W
R758 R92-1368-05 CHIP R 0 OHM
R759 R92-1252-05 CHIP R 0 OHM J 1/16W
R760 R92-1368-05 CHIP R 0 OHM
R903 RK73HB1J102J CHIP R 1.0K J 1/16W
R913-916 RK73HB1J102J CHIP R 1.0K J 1/16W
R923 R92-1252-05 CHIP R 0 OHM J 1/16W
S1 S70-0424-05 TACT SWITCH
S2 S70-0457-05 TACT SWITCH
S3,4 S70-0424-05 TACT SWITCH
D1 RB521S-30 DIODE
D4 MA2S111 DIODE
D16,17 MA2S111 DIODE
D24-27 MA2S111 DIODE
D28-31 RB706F-40 DIODE
D32 DA221 DIODE
D33 AVRM1608270MAB VARISTOR
D501 MA2S077 DIODE
D502,503 HSC277 DIODE
D505 1SV325F VARIABLE CAPACITANCE DIODE
D507 1SV325F VARIABLE CAPACITANCE DIODE
D509 1SV325F VARIABLE CAPACITANCE DIODE
D511 1SV325F VARIABLE CAPACITANCE DIODE
D513 1SV278F VARIABLE CAPACITANCE DIODE
D514-516 HSC277 DIODE
D517 MA2S077 DIODE
D601 UDZS4.7B ZENER DIODE
D604-606 HVC131 DIODE
D608 HVC131 DIODE
D701,702 DAN235E DIODE
D703-708 HVC350B VARIABLE CAPACITANCE DIODE
D901 1SR154-400 DIODE
IC1 XC61CC5002NR MOS-IC
IC2 XC6204B502PR MOS-IC
IC3 XC61CN3402NR MOS-IC
IC4,5 BU4094BCFV MOS-IC
IC6 LC75834W MOS-IC
IC7 30625MGP234HU MICROPROCESSOR IC
IC8 AT29C040A-90TU ROM IC
IC9 CAT24WC64WI ROM IC
IC10-12 TK62012F MOS-IC
IC13 AQUA-L MOS-IC
IC14 TC7W53FK(F) MOS-IC
IC15 TK62012F MOS-IC
IC16 M62364FP-F MOS-IC
IC17 TK62012F MOS-IC
IC18 TA7368F MOS-IC
IC19 TC75S51FE(F) MOS-IC
IC501 ADF4111BCP7 MOS-IC
IC601 TA75W01FUF MOS-IC
IC701 TA31136FNG MOS-IC
Q1 UMG3N TRANSISTOR
Q4 FP210 TRANSISTOR
Q5 UPA672T FET
Q6 UMG3N TRANSISTOR
Q7 UPA672T FET
Q8 DTA114EE DIGITAL TRANSISTOR
Q9 SSM6J08FU(F) FET
Q12 2SC4617(S) TRANSISTOR
Q13 2SB1132(Q,R) TRANSISTOR
Q14,15 SSM3K15TE(F) FET
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-7012-72)
To Next Page
