TK-3170
10
PARTS LIST
Q16 2SA1774(S) TRANSISTOR
Q17 2SC4649(N,P) TRANSISTOR
Q19 SSM3K15TE(F) FET
Q21 RN4910(F) TRANSISTOR
Q22 SSM3K15TE(F) FET
Q23 DTC144EE DIGITAL TRANSISTOR
Q24 SSM6J08FU(F) FET
Q25 2SK1830F FET
Q26 2SJ347F FET
Q27 DTC144EE DIGITAL TRANSISTOR
Q28 SSM3K01T(F) FET
Q29 SSM3K15TE(F) FET
Q30 2SJ243 FET
Q31,32 2SC4649(N,P) TRANSISTOR
Q33 2SJ347F FET
Q34 SSM3K15TE(F) FET
Q35 SSM3K01T(F) FET
Q501 2SC5488 TRANSISTOR
Q502,503 2SK508NV(K52) FET
Q504 SSM6P05FU(F) FET
Q505 2SC4617(S) TRANSISTOR
Q506,507 2SC5488 TRANSISTOR
Q601 2SC5488 TRANSISTOR
Q602 2SK3077F FET
Q603 RD01MUS1 FET
Q604 2SK3476 FET
Q605 DTC114EE DIGITAL TRANSISTOR
Q606 2SK879(GR) FET
Q607 DTC114EE DIGITAL TRANSISTOR
Q608 DTA144EE DIGITAL TRANSISTOR
Q609 SSM3K15TE(F) FET
Q701 2SC4649(N,P) TRANSISTOR
Q702 DTA144EE DIGITAL TRANSISTOR
Q703 2SC4649(N,P) TRANSISTOR
Q704,705 3SK318 FET
TH501 B57331V2104J THERMISTOR
TH701,702 B57331V2104J THERMISTOR
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-7012-72)
