TK-7160/7162
19
PARTS LIST
✽ New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L : Scandinavia K : USA P : Canada
Y : PX (Far East, Hawaii) T : England E : Europe
Y : AAFES (Europe) X : Australia M :Other Areas
11BA02-3898-02 PLASTIC CABINET
23A✽ A62-1107-13 PANEL ASSY 60E
23A✽ A62-1108-03 PANEL ASSY 62E
33AB42-7729-04 STICKER (WEEE)
41C✽ B62-1863-00 INSTRUCTION MANUAL
83BE04-0454-05 RF COAXIAL RECEPTACLE (BNC)
10 2B E30-3448-05 DC CORD
11 3C E30-7523-05 DC CORD ASSY ACCESSORY
12 3A E37-0962-05 SPEAKER CABLE
13 2A E37-1187-05 FLAT CABLE
15 2B F10-2491-12 SHIELDING COVER (UPPER)
16 3B F10-3011-03 SHIELDING CASE
17 2B F10-3019-03 SHIELDING CASE
18 2B F10-3047-13 SHIELDING PLATE
20 3C F52-0023-05 FUSE (BLADE TYPE) ACCESSORY
22 2B G02-1825-03 EARTH SPRING
23 3B G02-1826-03 EARTH SPRING
24 2B G02-1827-14 EARTH SPRING
25 2B G10-0792-14 FIBROUS SHEET
26 2A G10-1324-04 FIBROUS SHEET (DISPLAY)
28 2B G13-2119-04 CONDUCTIVE CUSHION
29 1B G53-1524-02 PACKING
30 2B G53-1542-03 PACKING
31 3B G53-1664-03 PACKING
33 2C,1D H12-3178-05 PACKING FIXTURE
34 3D H13-1190-02 CARTON BOARD
35 1C H25-2320-04 PROTECTION BAG
36 1C H25-2341-04 PROTECTION BAG
37 2C H52-2078-02 ITEM CARTON CASE 60E
37 2C H52-2087-02 ITEM CARTON CASE 62E
39 3D J29-0662-03 BRACKET ACCESSORY
41 3A K29-9342-01 KEY TOP
A2BN67-3008-48 PAN HEAD SEMS SCREW
B2A✽ N80-2008-48 PAN HEAD TAPTITE SCREW
C 2B,3B N87-2606-48 BRAZIER HEAD TAPTITE SCREW
D 1B,2B N87-2614-48 BRAZIER HEAD TAPTITE SCREW
43 3D N99-2048-05 SCREW SET
45 3A T07-0753-05 SPEAKER
101 2A B11-1829-03 ILLUMINATION GUIDE
102 2A B38-0902-05 LCD
D1-6 B30-2282-05 LED (Y)
D7-18 B30-2281-05 LED (Y)
D22 B30-2151-05 LED (RED/GREEN)
C1 CK73GB1H103K CHIP C 0.010UF K
C6,7 CK73GB1H102K CHIP C 1000PF K
C9 CK73GB1H102K CHIP C 1000PF K
C10 CK73GB1H103K CHIP C 0.010UF K
C11-14 CK73GB1H102K CHIP C 1000PF K
C15 CK73GB1H471K CHIP C 470PF K
C16,17 CK73GB1A105K CHIP C 1.0UF K
C18 CK73GB1C104K CHIP C 0.10UF K
C19,20 CC73GCH1H101J CHIP C 100PF J
C21 CK73GB1H681K CHIP C 680PF K
C22,23 CK73GB1H102K CHIP C 1000PF K
C24 CK73GB1H103K CHIP C 0.010UF K
C25 CK73GB1H102K CHIP C 1000PF K
C27 CC73GCH1H101J CHIP C 100PF J
C30 CK73GB1H102K CHIP C 1000PF K
103 2A E29-1206-05 INTER CONNECTOR
CN1 E40-6005-05 FLAT CABLE CONNECTOR
J1 E08-0877-05 MODULAR JACK
104 2A G10-1348-04 FIBROUS SHEET
105 2A J21-8494-03 MOUNTING HARDWARE
- J31-0553-05 COLLAR
L1 L92-0138-05 CHIP FERRITE
CP1 R90-0724-05 MULTI-COMP 1K X4
R1 RK73GB1J101J CHIP R 100 J 1/16W
R2 RK73GB1J100J CHIP R 10 J 1/16W
R3-5 RK73GB1J102J CHIP R 1.0K J 1/16W
R6-8 RK73GB1J103J CHIP R 10K J 1/16W
R9 RK73GB1J563J CHIP R 56K J 1/16W
R10,11 RK73FB2A331J CHIP R 330 J 1/10W
R14 RK73FB2A473J CHIP R 47K J 1/10W
R15,16 RK73FB2A330J CHIP R 33 J 1/10W
R17,18 RK73FB2A390J CHIP R 39 J 1/10W
R19 RK73GB1J392J CHIP R 3.9K J 1/16W
R20 R92-0670-05 CHIP R 0 OHM
R21 R92-1252-05 CHIP R 0 OHM J 1/16W
R22 RK73FB2A181J CHIP R 180 J 1/10W
R23 RK73FB2A820J CHIP R 82 J 1/10W
R24,25 RK73GB1J103J CHIP R 10K J 1/16W
R26,27 RK73GB1J102J CHIP R 1.0K J 1/16W
R28-31 RK73GB1J390J CHIP R 39 J 1/16W
D20,21 MC2850 DIODE
IC1 PT6554LQ MOS-IC
Q1 RN47A4 TRANSISTOR
Q2 2SB1132(Q,R) TRANSISTOR
Q3 KRA225S DIGITAL TRANSISTOR
Q4 KRC102S DIGITAL TRANSISTOR
Q7,8 2SC3928A TRANSISTOR
101 2A B11-1829-03 ILLUMINATION GUIDE
102 2A B38-0905-05 LCD
D1-6 B30-2282-05 LED (Y)
D7-12 B30-2281-05 LED (Y)
D22 B30-2151-05 LED (RED/GREEN)
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
TK-7160/7162 (Y51-506X-XX)
DISPLAY UNIT (X54-3510-10)
DISPLAY UNIT (X54-3522-70)
TK-7160/7162
DISPLAY UNIT (X54-3510-10) : TK-7160
DISPLAY UNIT (X54-3522-70) : TK-7162
