TK-7160/7162
22
PARTS LIST
C463,464 CK73GB1H471K CHIP C 470PF K
C465 C92-0795-05 CHIP-TAN 22UF 10WV
C466,467 CK73GB1H471K CHIP C 470PF K
C468 CK73GB1H221K CHIP C 220PF K
C469 CC73GCH1H060B CHIP C 6.0PF B
C470 CC73GCH1H020B CHIP C 2.0PF B
C471 CC73GCH1H030B CHIP C 3.0PF B
C472 CK73GB1H102K CHIP C 1000PF K
C473 CK73GB1H221K CHIP C 220PF K
C474,475 CK73GB1H102K CHIP C 1000PF K
C476 CC73GCH1H180J CHIP C 18PF J
C477 CK73GB1H102K CHIP C 1000PF K
C478 CC73GCH1H100C CHIP C 10PF C
C479 CC73GCH1H220J CHIP C 22PF J
C480 CC73GCH1H101J CHIP C 100PF J
C481-483 CK73GB1H102K CHIP C 1000PF K
C484 CK73GB1H221K CHIP C 220PF K
C487 CC73GCH1H110G CHIP C 11PF G
C501,502 CK73GB1H102K CHIP C 1000PF K
C503 CC73GCH1H101J CHIP C 100PF J
C504-507 CK73GB1H102K CHIP C 1000PF K
C509 CC73GCH1H150J CHIP C 15PF J
C510 CC73GCH1H080B CHIP C 8.0PF B
C513-515 CK73GB1H102K CHIP C 1000PF K
C516 CC73GCH1H270J CHIP C 27PF J
C517 CC73GCH1H220J CHIP C 22PF J
C518 CC73GCH1H470J CHIP C 47PF J
C519 CC73GCH1H101J CHIP C 100PF J
C523 CK73FB1H102K CHIP C 1000PF K
C527 CS77AA0J470M CHIP-TAN 47UF 6.3WV
C528,529 CK73GB1H102K CHIP C 1000PF K
C530 CK73GB1H221K CHIP C 220PF K
C531 CK73GB1C104K CHIP C 0.10UF K
C532 CK73GB1H471K CHIP C 470PF K
C533 C92-0719-05 ELECTRO 47UF 25WV
C535 CC73GCH1H101J CHIP C 100PF J
C536 CC73GCH1H470J CHIP C 47PF J
C541 CC73GCH1H220J CHIP C 22PF J
C554 C93-0557-05 CHIP C 7.0PF D
C555,556 C93-0563-05 CHIP C 18PF J
C557 CK73GB1H102K CHIP C 1000PF K
C558,559 CK73GB1H103K CHIP C 0.010UF K
C601 CC73GCH1H120J CHIP C 12PF J
C603 C93-0603-05 CHIP C 1000PF K
C606 CC73GCH1H0R5B CHIP C 0.5PF B
C607 CC73GCH1H010B CHIP C 1.0PF B
C608,609 C93-0564-05 CHIP C 22PF J
C613 C93-0555-05 CHIP C 5.0PF C
C614 C93-0562-05 CHIP C 15PF J
C615 CC73GCH1H0R5B CHIP C 0.5PF B
C616 CC73GCH1H020B CHIP C 2.0PF B
C618 CK73GB1H102K CHIP C 1000PF K
C620 CK73GB1H102K CHIP C 1000PF K
C626 C93-0553-05 CHIP C 3.0PF C
C651 CK73GB1H103K CHIP C 0.010UF K
C652 CK73GB1H102K CHIP C 1000PF K
C672,673 CK73GB1H102K CHIP C 1000PF K
TC441,442 C05-0245-05 CERAMIC TRIMMER (10PF)
CN1 E40-6268-05 FLAT CABLE CONNECTOR
CN2 E40-5702-05 PIN ASSY
CN3 E40-6292-05 PIN ASSY
CN5 E40-3246-05 PIN ASSY
CN301-304 E23-1081-05 TERMINAL
CN501-503 E23-1081-05 TERMINAL
CN504-506 E23-1262-05 TERMINAL
J1 E11-0425-05 3.5D PHONE JACK (3P)
F41 F53-0246-05 FUSE
CF331 L72-0993-05 CERAMIC FILTER
CF332 L72-0999-05 CERAMIC FILTER
L1,2 L92-0179-05 CHIP FERRITE
L101 L92-0443-05 CHIP FERRITE
L211 L92-0443-05 CHIP FERRITE
L321 L34-4554-05 COIL
L341 L41-3385-08 SMALL FIXED INDUCTOR (330NH)
L342,343 L40-3381-86 SMALL FIXED INDUCTOR (0.33UH)
L351 L41-8285-08 SMALL FIXED INDUCTOR (820NH)
L352 L41-5685-08 SMALL FIXED INDUCTOR (560NH)
L354,355 L34-4612-05 AIR-CORE COIL
L356 L34-4613-05 AIR-CORE COIL
L357 L34-4610-05 AIR-CORE COIL
L402 L41-1005-08 SMALL FIXED INDUCTOR (10UH)
L404 L92-0442-05 CHIP FERRITE
L421 L92-0443-05 CHIP FERRITE
L441,442 L40-2785-92 SMALL FIXED INDUCTOR (270NH)
L443 L41-3378-14 SMALL FIXED INDUCTOR (33NH)
L444,445 L40-2702-86 SMALL FIXED INDUCTOR (27UH)
L446,447 L40-2785-92 SMALL FIXED INDUCTOR (270NH)
L448 L41-4778-14 SMALL FIXED INDUCTOR (47NH)
L449,450 L40-2702-86 SMALL FIXED INDUCTOR (27UH)
L451-453 L92-0443-05 CHIP FERRITE
L454 L41-3375-06 SMALL FIXED INDUCTOR (33NH)
L455 L41-1085-06 SMALL FIXED INDUCTOR (100NH)
L456 L41-1585-06 SMALL FIXED INDUCTOR (150NH)
L457 L41-1085-06 SMALL FIXED INDUCTOR (100NH)
L458 L41-5675-06 SMALL FIXED INDUCTOR (56NH)
L501,502 L41-6875-08 SMALL FIXED INDUCTOR (68NH)
L503 L34-4757-05 AIR-CORE COIL
L504 L92-0179-05 CHIP FERRITE
L509 L34-4753-05 AIR-CORE COIL
L601 L34-4759-05 AIR-CORE COIL
L603,604 L34-4755-05 AIR-CORE COIL
L605 L34-4753-05 AIR-CORE COIL
X86 L77-1970-05 CRYSTAL RESONATOR (12.0MHZ)
X241 L77-1968-05 CRYSTAL RESONATOR (3.6864MHZ)
X401 L77-1944-05 TCXO (16.8MHZ)
XF351 L71-0624-05 MCF (49.95MHZ)
CP1-7 RK75HA1J102J CHIP-COM 1.0K J 1/16W
R1 R92-1252-05 CHIP R 0 OHM J 1/16W
R2 RK73HB1J101J CHIP R 100 J 1/16W
R3 RK73HB1J102J CHIP R 1.0K J 1/16W
R4 RK73HB1J332J CHIP R 3.3K J 1/16W
R5 RK73HB1J223J CHIP R 22K J 1/16W
R41 RK73GB1J473J CHIP R 47K J 1/16W
R42 R92-1201-05 CHIP R 220 J 1/2W
R43 RK73GB1J473J CHIP R 47K J 1/16W
R44 RK73GB1J472J CHIP R 4.7K J 1/16W
R45 RK73GB1J473J CHIP R 47K J 1/16W
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-7102-70)
To Next Page
