Kenwood TK-7162 E - PARTS LIST (Continued); TX-RX Unit Parts List

TK-7160/7162
25
PARTS LIST
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-7102-70)
D401 1SS355 DIODE
D421 HZU5ALL DIODE
D441-444 MA2S304 VARIABLE CAPACITANCE DIODE
D445 1SV278 VARIABLE CAPACITANCE DIODE
D446 1SS355 DIODE
D447,448 HSC277 DIODE
D501 1SS355 DIODE
D503 02DZ5.1(Y) ZENER DIODE
D602 MA4PH633 DIODE
D603 XB15A709 DIODE
D606 MA742 DIODE
D608 MA742 DIODE
D609,610 1SS355 DIODE
IC41 KIA7808AF ANALOGUE IC
IC42,43 NJM78L05UA BI-POLAR IC
IC44,45 BD4740G MOS-IC
IC81 AT24C12810SU18 ROM IC
IC101 30624FGPGKAGA MICROCONTROLLER IC
IC201 M62364FP MOS-IC
IC211 NJM2100V MOS-IC
IC213 BU4066BCFV MOS-IC
IC214,215 BA10358FV MOS-IC
IC241 AQUA-L MOS-IC
IC281 2B LA4600 BI-POLAR IC
IC321 TK14489V BI-POLAR IC
IC401 MB15A02 MOS-IC
IC402 UPB1509GV BI-POLAR IC
IC502 2B RA30H1317M-31 MOS-IC
IC651 TA75W01FU MOS-IC
Q31 2B ✽ 2SJ650 TRANSISTOR
Q42 2SD1757K TRANSISTOR
Q43 2SA1745(6,7) TRANSISTOR
Q44 KRC102S DIGITAL TRANSISTOR
Q45 KTA1664(Y) TRANSISTOR
Q46 KRC102S DIGITAL TRANSISTOR
Q81 RT1N441U TRANSISTOR
Q82,83 2SK1830 FET
Q84 KRC414RTK DIGITAL TRANSISTOR
Q201 2SC2412K TRANSISTOR
Q211 2SC4919 TRANSISTOR
Q212,213 2SK1830 FET
Q241 RT1P141U TRANSISTOR
Q242,243 2SC4649(N,P) TRANSISTOR
Q281 DTC363EU DIGITAL TRANSISTOR
Q282 KRC102S DIGITAL TRANSISTOR
Q301 2SC2412K TRANSISTOR
Q341 2SC3928A TRANSISTOR
Q351 2SC5488 TRANSISTOR
Q352,353 3SK318 FET
Q421 2SA1832(GR) TRANSISTOR
Q422 2SC4738(GR) TRANSISTOR
Q431 2SC4649(N,P) TRANSISTOR
Q441 2SK508NV(K52) FET
Q442 2SJ347 FET
Q443 KRX102U TRANSISTOR
Q444 2SK508NV(K52) FET
Q445 2SC2412K TRANSISTOR
Q446 2SC5108(Y) TRANSISTOR
Q447 2SC4649(N,P) TRANSISTOR
Q501 2SC3357(RF) TRANSISTOR
Q502 RD00HVS1 FET
TH301 B57331V2104J THERMISTOR
TH672,673 B57331V2104J THERMISTOR
