Kenwood TK-7162 E - ADJUSTMENT (Continued); Squelch Adjustment; Transmitter Power Adjustment

TK-7160/7162
31
2. Squelch 9 1) CH : RX low (Wide) PC key Adjust to open the squelch
CH : RX center
(Wide/Wide 4k/Narrow)
CH : RX high (Wide)
2) SSG output
: 12dB SINAD+7dB
Mod : 1kHz
Dev : ±3.0kHz (Wide)
Dev : ±2.4kHz (Wide 4k)
Dev : ±1.5kHz (Narrow)
3. Squelch 1 1) CH : RX low (Wide)
CH : RX center
(Wide/Wide 4k/Narrow)
CH : RX high (Wide)
2) SSG output
: 12dB SINAD+2dB
Mod : 1kHz
Dev : ±3.0kHz (Wide)
Dev : ±2.4kHz (Wide 4k)
Dev : ±1.5kHz (Narrow)
4. RSSI 1) CH : RX low
–80dBm CH : RX center
CH : RX high
2) SSG output
: –80dBm (22.4µV)
Dev : OFF
5. RSSI 1) CH : RX low
–120dBm CH : RX center
CH : RX high
2) SSG output
: –120dBm (0.22µV)
Dev : OFF
Item Condition
Test equipment Terminal Parts Method
Specifications/
Remarks
Measurement
Adjustment
ADJUSTMENT
Item Condition
Test equipment Terminal Parts Method
Specifications/
Remarks
Measurement
Adjustment
Transmitter Section
1. Frequency 1) CH : TX center Frequency counter ANT PC key Adjust to center frequency Within ± 100Hz
2) Transmit
2. Maximum 1) CH : TX high Power meter 28W ± 1W
power 2) Transmit
limitting
3. High 1) CH : TX low 25W ± 1.0W
power CH : TX low’
CH : TX center
CH : TX high’
CH : TX high
2) Transmit
