Electrical parts list
MAIN UNIT
XC1-1172-70
Block No. [0][1]
Symbol No.
Part No. Part Name Description Local
IC2 AK1541 IC
IC3 BD7542FVM IC
IC400 AK2365A IC
IC600 PST8256U IC
IC601 XC6209B502P-G IC
IC602 MM1856A50N IC
IC603 XC6209B502P-G IC
IC604 LDK220M33R IC
IC605 BU4830F IC
IC606 LDK220M33R IC
IC650 TPS62140RGT IC
IC700 E25Q40A104GIP IC
IC703 MM1856A33N IC
IC704 BU7465HFV IC
IC705 CMX7241 IC
IC706 BU7465HFV IC
IC707 TA7368FG IC
IC708 BU7465HFV IC
IC709 NJU7089KV1 IC
IC710 2F405VGT6KGEA IC
IC713 SM5023CNDH-G IC
IC715 MM1856A33N IC
IC717 BU7465HFV IC
IC719 TC7W53FKF IC
IC720 TC7W53FKF IC
IC721 BU7465HFV IC
IC832 BU7465HFV IC
Q1 SSM3J05FU-F FET
Q3 RE1C001UN FET
Q4 KTC4075EP/YG/ TRANSISTOR
Q5 MCH3914-H/8/ FET
Q6 MCH3914-H/8/ FET
Q7 EM6M2 FET
Q8 SSM3J36TUT FET
Q9 2SC5108F/Y/ TRANSISTOR
Q10 2SC5108F/Y/ TRANSISTOR
Q11 2SC5108F/Y/ TRANSISTOR
Q201 2SC5455-A TRANSISTOR
Q206 RFM01U7PF FET
Q208 RD07MUS2BT214 FET
Q290 SSM3J36TUT FET
Q291 SSM3J36TUT FET
Q297 EMD9 TRANSISTOR
Q298 LTC044EEBFS8 DIGI TRANSISTOR
Q400 2SC5108F/Y/ TRANSISTOR
Q403 KTC4075EP/YG/ TRANSISTOR
Q404 3SK318YB-E FET
Q405 3SK318YB-E FET
Q600 LTC014EEBFS8 DIGI TRANSISTOR
Q601 EM6M2 FET
Q602 EM6M2 FET
Q603 SSM3K127TUT FET
Q604 LTC014EEBFS8 DIGI TRANSISTOR
Q605 LTC014EEBFS8 DIGI TRANSISTOR
Q606 SSM3J36TUT FET
Q620 LTC044EEBFS8 DIGI TRANSISTOR
Q703 UM6K34N FET
Q704 KTC4075EP/YG/ TRANSISTOR
Q705 2SC4116F/G/ TRANSISTOR
Q706 2SA1586F/YG/ TRANSISTOR
Q707 NTJD4001NG FET
Q708 LTC014EEBFS8 DIGI TRANSISTOR
Q709 LTC014EEBFS8 DIGI TRANSISTOR
Q710 2SB1694 TRANSISTOR
Q711 LTC014EEBFS8 DIGI TRANSISTOR
Q712 LTC044EEBFS8 DIGI TRANSISTOR
Q713 SSM3K324RF FET
Q714 2SB1132(Q,R) TRANSISTOR
Q715 UMG3N DIGI TR ARRAY
Q716 SSM3K324RF FET
D4 BBY56-02V VARI CAP DIODE
D5 BBY56-02V VARI CAP DIODE
D8 1SV325FT VARI CAP DIODE
D9 1SV325FT VARI CAP DIODE
D10 KDS160E-P DIODE
D11 1SV325FT VARI CAP DIODE
D12 1SV325FT VARI CAP DIODE
D13 BB664-02V VARI CAP DIODE
D14 1SS390 DIODE
D15 1SS390 DIODE
D16 1SV325FT VARI CAP DIODE
D17 1SV325FT VARI CAP DIODE
D201 RN142S DIODE
D202 RN142S DIODE
D203 RN142S DIODE
D204 RN142S DIODE
D400 1SV305F VARI CAP DIODE
D401 1SV305F VARI CAP DIODE
D402 1SV305F VARI CAP DIODE
D403 1SV305F VARI CAP DIODE
D404 1SV305F VARI CAP DIODE
D405 1SV305F VARI CAP DIODE
D600 RB521S-30-TP DIODE
D601 SML-512MW LED
D602 SML-512VWA LED
D603 GS1G-L DIODE
D604 SMLE12BC7TV LED
D605 UDZW5.1B ZENER DIODE
D620 DAN222 DIODE ARRAY
D630 DB2S310 SCHOTTKY DIODE
D700 RB706F-40-MC DIODE
D701 RB706F-40-MC DIODE
D702 1SS372F SCHOTTKY DIODE
D703 MC2850-1 DIODE ARRAY
D754 RB706F-40-MC DIODE
C6 CC73HCH1H101J C CAPACITOR 100pF 50V J
C7 CC73HCH1H100B C CAPACITOR 10pF 50V B
C8 CK73HBB1E103K C CAPACITOR 0.01uF 25V K
C9 CC73HCH1H101J C CAPACITOR 100pF 50V J
C11 CC73HCH1H100B C CAPACITOR 10pF 50V B
C13 CC73HCH1H101J C CAPACITOR 100pF 50V J
C15 CK73HBB1E103K C CAPACITOR 0.01uF 25V K
C16 CK73HBB1E103K C CAPACITOR 0.01uF 25V K
C18 CK73HB1H271K C CAPACITOR 270pF 50V K
C19 CK73HBB1E103K C CAPACITOR 0.01uF 25V K
C20 CK73HBB1A104K C CAPACITOR 0.1uF 10V K
C22 CK73HB1H271K C CAPACITOR 270pF 50V K
C23 CK73HBB1E103K C CAPACITOR 0.01uF 25V K
C26 CS77MA1D010M TA E CAPACITOR 1uF 20V M
C27 CK73HB1H271K C CAPACITOR 270pF 50V K
C28 CK73HB1H271K C CAPACITOR 270pF 50V K
C29 CS77AAV1V0R1M TA E CAPACITOR 0.1uF 35V M
C30 CK73HB1H271K C CAPACITOR 270pF 50V K
C32 CK73HB1H271K C CAPACITOR 270pF 50V K
C33 CC73HCH1H330J C CAPACITOR 33pF 50V J
C34 CK73HBB1A104K C CAPACITOR 0.1uF 10V K
C35 CC73HCH1H050B C CAPACITOR 5pF 50V B
C36 CC730AD1H104J C CAPACITOR 0.1uF 50V J
C37 CC73HCH1H030B C CAPACITOR 3pF 50V B
C38 CK73HB1H271K C CAPACITOR 270pF 50V K
C39 CK73GB0J106K C CAPACITOR 10uF 6.3V K
C40 CC73HCH1H050B C CAPACITOR 5pF 50V B
C42 CK73HBB1A104K C CAPACITOR 0.1uF 10V K
C46 CK73HB1H271K C CAPACITOR 270pF 50V K
C47 CK73HB1H271K C CAPACITOR 270pF 50V K
C54 CC73HCH1H0R5B C CAPACITOR 0.5pF 50V B
C56 CS77PBQ1C100M TA E CAPACITOR 10uF 16V M
C57 CC73HCH1H050B C CAPACITOR 5pF 50V B
C58 CC73HCH1H040B C CAPACITOR 4pF 50V B
C60 CC73HCH1H050B C CAPACITOR 5pF 50V B
C61 CC73HCH1H050B C CAPACITOR 5pF 50V B
C62 CC73HCH1H050B C CAPACITOR 5pF 50V B
C63 CC73HCH1H050B C CAPACITOR 5pF 50V B
Symbol No.
Part No. Part Name Description Local
