11.6 Remote control instructions
Instruction: Function
“T” = H54
Taring
“C” = H43
Adjustment
“E” = H45
Enter
“M” = H4D
Menu
“O” = H4F
ON/OFF
11.7 Printer mode
The following conditions must be met to provide successful communication between
the weighing balance and the printer.
• Use a suitable cable to connect the weighing balance to the interface of the
printer. Faultless operation requires an adequate KERN interface cable.
• The Baud rates of balance and printer must agree, see chap. 9.3.
Printout examples:
Weighing mode/peak value function
Density determination
d
Measuring value „Density“
Parts counting
PCS
Number of pieces
Weight
Weight of placed pieces
PMU
Average parts weight
………. 22.000 g
d= 2.80066 g/cm3d
Pcs 100
Weight: 300.000 g
PMU: 3.000 g
