KERN ALJ Series - Page 94

ALJ/ALS/PLJ/PLS-BA-e-1640
16
KERN PLS 8000-2A
PLS 20000-1F
Weighing range (max)
8200 g 20 kg
Readability (d)
0.01 g 0.1 g
Reproducibility
0.01 g 0.1 g
Linearity
± 0.03 g ± 0.4 g
Stabilization time (typical)
2 sec. 3 sec.
Minimum unit weight at
piece counting
> 50 mg > 500 mg
Warm-up time
4 Stunden 4 hours
Recommended adjustment
weight, not added (class)
5 kg (E2) 20 kg (E2)
Reference quantities at
piece counting
10, 25, 50, 100, freely selectable
Weighing Units
ct, g, gn, lb, mo, oz, ozt,
tl (HK), tl (Singap. Malays), tl (Tw), pen
Electric Supply
230V/50 Hz (Euro)
24V AC
230V/50 Hz (Euro)
9V DC
Operating temperature
+ 5° C …. + 35° C
Humidity of air
max. 80 % (not condensing)
Underfloor weighing
Clevis type eyelet, standard
Housing (B x D x H) mm
210 x 340 x 100 210 x 340 x 100
Windshield mm no no
Weighing plate
(stainless steel)
Ø 16 cm 200 x 175 mm
Weight kg (net)
4.75 kg 4 kg
Interface
RS 232C
