KERN ITB Service Manual

FTx/ITx-SH-e-0720 11
Item Qty. Description Order No.
1 4 adjustable foot Ø 44 mm (M10 x 0.75mm) 21203434
2 6 countersunk Torx screw M4 x 12 *
3 1 bottom plate for small platform model –
4 4 button head Torx screw M4 x 12 *
5 4 wide flange washer 4.3 x 20 *
6 4 overload spring **
7 1 overload stop adjustment screw (with certain production series only) **
8 2 countersunk Torx screw M6 x 16 *
9 1 overload plate for small platform model –
10 1 weighing cell with cable (certifiable)
weighing range 3 kg:
LC0765-5-MRV (Standard cell) 21203873
LC0765-5-6TV (Premium cell) 21203877
weighing range 6 kg:
LC0765-10-MRV (Standard cell) 21203874
LC0765-10-6TV (Premium cell) 21203878
11 1 bench AC adapter (always order together with item 16):
EURO version 22011363
USA version 22011364
UK version 22011365
JAPAN version 22011366
Australian version 22011367
external power supply unit (battery charger) for operation with a storage battery
(without power cable) 22011300
socket for external power supply unit 22011311
12 2 spring clip *
13 1 analog PCB BBA AN DMS 7k 21203092
14 1 RS cable 460 mm 21203168
15 1 A/D cable 110mm, for small platform model 21203164
16 1 adhesive patch for AC adapter or battery (for battery version order 2 pcs.) 21203184
17 1 RS connector plate –
(various types, depending on the equipment)
18 4 raised cheese head Torx screw M4 x 6 *
19 for scales with AccuPac only:
19a 1 accu 14.4V NiMH (always order together with item 16) 22011349
19b 1 battery connection cable –
19c 1 print charger NiMH 22011351
19d 1 battery cable (charging PCB – analog PCB) 21203233
*included in the small parts set (Chapter 4.5) ** see Chapter 5.8 "Replacing the weighing cell"
19d 1
battery cable (charging PCB - analog PCB)
21203233
