FTx/ITx-SH-e-0720 23
Item Qty. Description Order No.
1 4 adjustable foot Ø 55mm (M10 x 0.75 mm) 21203433
2 11 countersunk Torx screw M4 x 10 *
3 1 bottom plate for large platform model –
4 4 button head Torx screw M5 x 12 *
5 4 wide flange washer 5.3 x 20 *
6 4 overload spring **
7 1 overload stop adjustment screw (with specific production series only) **
8 2 countersunk Torx screw M6 x 16 *
9 1 overload plate for large platform model –
10 1 weighing cell with cable (certifiable)
weighing range 15 kg:
LC0785-20-MRV (standard cell) 21203885
LC0785-20-6TV (premium cell) 21203889
weighing range 35 kg:
LC0785-50-MRV (standard cell) 21203886
LC0785-50-6TV (premium cell) 21203890
weighing range 60 kg:
LC0785-100-MRV (standard cell) 21203887
LC0785-100-6TV (premium cell) 21203891
11 1 bench AC adapter (always order together with item 16):
EURO version 22011363
USA version 22011364
UK version 22011365
JAPAN version 22011366
Australian version 22011367
external power supply unit (battery charger) for operation with a storage battery
(without power cable) 22011300
socket for external power supply 22011311
12 2 spring clip *
13 1 analog PCB BBA AN DMS 7k 21203092
14 1 RS cable 460 mm 21203168
15 1 A/D cable 300 mm for large platform model 21203167
16 1 adhesive patch for AC adapter 21203184
2 adhesive patch for battery, thick 21255260
2 adhesive patch for battery, thin 21203184
17 1 RS connector plate (various types, depending on the equipment) –
18 4 raised cheese head Torx screw M4 x 8 *
