26 FTx/ITx-SH-e-0720

Item Qty. Description Order No.

1 1 packing for cover plate 21203235

2 1 cover plate –

3 2 countersunk Torx screw M3 x 8 *

4 1 flange D = 100 mm –

5 1 diaphragm 21203077

6 1 flange D = 58 mm –

7 3 countersunk Torx screw M3 x 10 *

8 4 countersunk Torx screw M3 x 8 *

9 2 EMC clamp 21203480

* included in the small parts set (Chapter 4.5)

Note: Parts of the scale not numbered in the illustration are included in the normal version (Chapter 3.1).
