36 FTx/ITx-SH-e-0720
Item Qty. Description Order No.
1 1 base plate with seal attached 21255118
2 4 rubber foot 00200068
3 8 countersunk screw M4 x 12 Torx T20 *
41 bench AC adapter 8VA (always order together with item 5):
EURO version 22011363
USA version 22011364
UK version 22011365
JAPAN version 22011366
Australian version 22011367
external power supply unit (battery charger) for operation with a storage battery
(without power cable) 22011300
socket for external power supply unit 22011311
5 1 adhesive tape for AC adapter 21203184
6 1 seal for terminal rear panel 21255012
7 1 connector plate for 1 interface (RS232C/load cell) standard –
8 1 countersunk screw M4 x 12 Torx T20 *
9 5 fillister head screw M4 x 8 Torx T20 *
10 1 RS232C interface IP65 with cable (soldered) 21203717
11 2 dust cover for interfaces 11101560
12 1 keypad overlay KMS-TM 22011415
13 1 display mounting plate (always order together with item 12) 22010038
14 1 LCD 21203687
15 1 backlighting 21203137
16 1 digital board with FLASH Memory Chip (soldered) 21204025
17 2 Torx oval head tapping screw 2.9 x 13 (red) *
18 1 analog board 7 k 21255054
19 1 fastening clamp for analog board * *
20 1 A/D cable 300 mm 21203167
21 1 EMC clamp short 21203480
22 1 EMC clamp long 21255047
23 4 screw lock *
24 1 EMC clamp for analog board 22007948
* included in the small parts set (Chapter 4.5)
