18 TALJG_A/TALSG_A/TPLJG_A/TPLSG_A-BA-e-2112
Models PLS
scale plate dimensions Ø 160 mm
Models PLS 20000-1F
scale plate dimensions 200 x 175 mm
Item Name
1 Leveler
2 Scale plate
3 Display
4 Keyboard
5 Leveling screw foot
Sample drawing with a ionizing unit installed (KERN ALJ-A03):
