13.3 Interface
• Scale–computer, 25-pin plug
• Scale–computer, 9-pin plug
• Scale–printer
Scale
PC
Scale
PC
Input data
Busy signal
GND (weight)
2
4
5
Scale
Printer
Scale
side
Con
nect
or
Connector
25 Pins
3
2
7
6
20
2
3
5
6
4
Scale
side
PC
side
2
3
5
6
4
2
3
5
6
4

KERN PLS Series Specifications

General

Weighing plate material	stainless steel
Protection Class	IP65
Readability	0.1g
Reproducibility	0.1 g
Minimum part weight at piece counting	0.1 g
Permissible ambient temperature	40°C
Interface	RS-232
