Kernel KN-2200B - Page 18

Colposcope Digital Imaging System
14
15. Insert the fiber port A to the output hole of cold light source：
Pic 3-15
16. Lead the fiber into the rocker arm fixed deduction card：
Pic 3-16
17. Insert fiber port B into light input hole in the bottom of eyepiece stand，fixed the screw
F：
Pic 3-17
Fiber port A
fixed deduction card
Screw F
Fiber port B
