Kernel KN-2200B - Page 17

Colposcope Digital Imaging System
13
12. Install the screw D to the bottom of rocker arm and fix the eyepiece stand：
Pic 3-12
13. Fix the eyepiece to the stand and tighten the screw E ：
.
Pic.3-13
14. Fix the digital CCD to the eyepiece stand：
Pic 3-14
Screw D
Eyepiece
Screw E
Digital CCD
