9. Fix the screw C to the bottom of rocker arm：
Pic 3-9
10. Remove the screw D from the bottom of eyepiece stand：
Pic 3-10
11. Fix the eyepiece to the front of rocker arm：
Pic 3-11
Scew C
Screw D
Eyepiece stand
Rocker arm
