6. Fix the strut and light source with the four removed screws：
Pic 3-6
7. Remove the screws of the bottom of rocker arm：
Pic 3-7
8. Fix the rocker arm to the front of light source fixed hole:
Pic 3-8
Screw B
Screw C
Rocker arm
Cold light source
