RCD(EN61557-6)
Function Operating error of trip current
X1/2 -10%~0%
X1, X5 0%~+10%
Ramp -10%~+10%
The influencing variations used for calculating the operating error are denoted as follows;
Temperature : 0 ℃ and 35 ℃
Earth electrode Resistance (shall not exceed below) :
IΔn (mA)
Earth electrode resistance (Ω max.)
UL50V UL25V
10 2000 2000
30 600 600
100 200 200
300 130 65
500 80 40
1000 40 20
Table.1
System voltage: 230V+10%-15%
Supply voltage : 8V to 13.8V
5.3 General specification
Instrument dimensions 235 X 136 X 114mm
Instrument weight:- 1300g (including batteries.)
Reference conditions Specifications are based on the following
conditions except where otherwise stated:-
1. Ambient temperature: 23±5° C:
2. Relative humidity 45% to 75%
3. Position: horizontal
4. AC power source 230V, 50Hz
5. DC power source: 12.0 V, ripple content 1%
or less
6. Altitude up to 2000m, Indoor use
Battery type Eight LR6 or R6 batteries.
Operating temperature 0 to +40℃ , relative humidity 80% or less, no
and humidity. condensation
Storage temperature -20 to +60℃ , relative humidity 75% or less,
and humidity no condensation.
Specification
