Correct assembly is shown in Fig 37, 38 and 39. By hanging the instrument
round the neck, both hands will be left free for testing.
1. Attach the Buckle to the KT64 as shown in Fig.37.
2. How to install the Strap belt
3. How to fasten the Strap belt
Match the hole of the Buckle and
the protrusion at the side face of
KT64, and slide it upwards.
Pass the strap belt down through
the buckle from the top, and up
through the slots of the probe case
from the bottom.
Pass the strap through the buckle,
adjust the strap for length and
secure.
Fig. 37
Fig. 38
Fig. 39
18 Case
and strap
assembly
