Display Dot Matrix LCD 160(W) X 240(H) pixels.
Overload protection The continuity test circuit is protected by a
0.5A/600V fast acting (HRC) ceramic fuse
mounted in the battery compartment, where a
spare fuse is also stored.
The insulation resistance test circuit is
protected by a resistor against 1000 V AC for
10 seconds.
5.4 Applied standards
Instrument operating IEC/EN61557-1,2,3,4,6,10 (1997)
Standard
Safety standard IEC/EN 61010-1(2001),
CATIII (300V) -Instrument
IEC/EN 61010-031(2001),
CATII (250V)-Test Lead KAMP12
CATIII (600V)-Test Lead ACC064
CATIII (1000V)-Test Lead ACC064SP
Protection degree IEC 60529 (1989 + A1) IP40
EMC EN 61326
・
EN 55022
・
EN 61000-4-2 (performance criterion C)
・
EN 61000-4-3 (performance criterion B)
This manual and product may use the following symbols adopted from
International Safety Standards;
CAT.III Designed to protect against transient overvoltages in a building
wiring installation (low-voltage distribution level)
Equipment protected throughout by DOUBLE INSULATION
or REINFORCED INSULATION;
Caution (refer to accompanying documents)
Caution, risk of electric shock
Protection against wrong connection is up to 500V
Earth Ground
