Key-Disp KD58C - Product Overview; Model and Specifications; Appearance and Size

1
Product name and Model
Electric Bicycle Intelligent Display,
Model: KD58C.
Specifications
●24V/36V /48V Power Supply
●Rated current: 10mA
●The maximum working current: 30mA
●Off-state leakage current: <1μA
●Working temperature: -20 ~ 60 ℃
●Storage temperature: -30 ~ 70 ℃
Appearance and Size
Display appearance and dimensional drawing (unit: mm)
