Keyscan CA8500B Technical Instructions
5
of 1
of 1 rating
140 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Keyscan Inc.
–
Techn
ical Guide (PC10
9x - 04
.1
5)
33
Figure
20
–
Lock State
- Fail Safe De
vice
Figure
21
–
Lock State
- Fail Secure
Device
Maglock
+
-
to 'Normally Closed'
positon on relay
to common
on DC power supply
Relay board
Relay board
+
-
Door
Strike
Lock State
of
Fail Safe Device
DC
Supply
+
-
Lock
to 'Normally Closed'
positon on relay
to
+
supply
to common
on DC power supply
to
+
supply
KI-00124E-07-11
to
'Normally Open'
positon on relay
+
-
Door
Strike
to common
on DC
power supply
Lock State
of
Fail Secure Device
Lock
DC
Supply
+
-
to
+
supply
Relay board
KI-00125E-07-11
32
34
