Keyscan Inc. – Technical Guide (PC109x - 04.15)
55
S2 Switch #
Setting
Function
Notes
1 1
Program mode for NETCOMP plugged into M1
(COM4) on the control board
The H2 header for CIM connections is an open header and is not regulated by S2.
S2.9 & S2.10
KHS - IP Address
n/a
Reserved for Keyscan Hosted Services
S2.11 & S2.12
Software Selection
1 1
Aurora
0 0
System VII
1 0
Vantage
0 1
Future use
0 = Off
1 = On
Notes on Communication Settings
The 9600 bit/s communication setting is recommended for the CPB-10-2 only. Aurora does not support
this communication setting.
The 19,200 bit/s communication setting is only recommended for CPB-10-2 connections, which do not
exceed 200 ft/61 m between units and overall distance.
Aurora and all current hardware products do not support modem communication.
Ensure you are running the most current software version with this control board. For the latest software
updates, visit www.keyscan.ca.
