Specifications
Input Power Requirements
Powered through control board—NETCOM2P 140 mA + control board 130 mA = 270 mA
Powered through CIM—NETCOM2P 140 mA + CIM 150 mA = 290 mA
Network Interface
RJ45 (10/100 Base-T) Ethernet
LAN/ WAN (TCP/IP protocol—port 3001)
Agency Approvals—Ethernet Socket
Complies with Class B limits of EN 55022: 1998 Direct & Indirect ESD.
Complies with EN55024:1998
Dimensions
1 9/16” x 1 15/16” (41 mm x 49 mm)
Environmental
Suitable for industrial and commercial applications.
Operating temperatures: 5
0
C to 70
0
C (41
0
F to 158
0
F)
RJ45 Ethernet (Xport) LED States
The RJ45 Ethernet terminal has two bi-colour LEDs:
Link LED (left side)
Activity LED (right side)
Amber – flashing
10 Mbps
Amber – flashing
Half-duplex
Green – flashing
100 Mbps
Green – flashing
Full-duplex
Address Settings
*IP Address:
*Subnet Mask:
Gateway:
**Ethernet Connection
Type:
* Required fields for device configuration with software
** If other than Automatic Negotiation
