4 - Language Dictionary
40
Table 4-1. Subsystem Commands Syntax
ABORt
Resets the trigger system to the Idle state
CALibrate :
:CURRent
[:SOURce]
[:DC] [:POSitive]
:NEGative
Calibrate positive output current and high current
measurement range
Calibrate negative output current
:MEASure
[:DC] :LOWRange
Calibrate low current measurement range
:AC
Calibrate ac current measurement circuits
:DATA <n>
Input a calibration measurement
:LEVel <level>
Advance to next calibration step (P1 | P2)
:PASSword <n>
Set calibration password
:SAVE
Save new cal constants in non-volatile memory
:STATE <bool> [,<n>]
Enable or disable calibration mode
:VOLTage
[:DC]
Calibrate output voltage and voltage readback
:PROTection
Begin voltage protection calibration sequence
DISPlay
[:WINDow]
[:STATe] <bool>
Enable/disable front panel display
:MODE <mode>
Set display mode (NORM | TEXT)
:TEXT [:DATA] <string>
Sets the text that is displayed
INITiate
[:IMMediate]
:SEQuence[<n>]
Initiate a specific numbered sequence (1 | 2)
:NAME <name>
Initiate a specific named sequence (TRAN | ACQ)
CONTinuous
:SEQuence1, <bool>
Set continuous initialization
:NAME TRANsient, <bool>
Set continuous initialization
MEASure | FETCh
:ARRay
:CURRent [:DC]?
Returns the digitized instantaneous current
:VOLTage [:DC]?
Returns the digitized instantaneous voltage
[:SCALar]
:CURRent [:DC]?
Returns dc current
:ACDC?
Returns the total rms current (ac+dc)
:HIGH?
Returns the HIGH level of a current pulse
:LOW?
Returns the LOW level of a current pulse
:MAX?
Returns maximum current
:MIN?
Returns minimum current
:VOLTage [:DC]?
Returns dc voltage
:ACDC?
Returns the total rms voltage (ac+dc)
:HIGH?
Returns the HIGH level of a voltage pulse
:LOW?
Returns the LOW level of a voltage pulse
:MAX?
Returns maximum voltage
:MIN?
Returns minimum voltage
