Operation and Service Guide 1
Keysight E4412A and E4413A Operating and Service Guide 23
Installation
Initial inspection
Inspect the shipping container for damage. If the shipping container or packaging
material is damaged, it should be kept until the contents of the shipment have
been checked mechanically and electrically. If there is mechanical damage or if
the instrument does not pass the performance tests, notify the nearest Keysight
Technologies office. Keep the damaged shipping materials (if any) for inspection
by the carrier and a Keysight Technologies representative.
Table 1-2 E4413A maximum calibration factor uncertainty at calibrated
powers
Frequency
Uncertainty (%)
[a]
[a] Specifications apply to instruments with serial prefix US3848/MYxxxxxxxx/SGxxxxxxxx and above. For earlier
instruments, refer to Appendix A.
50 MHz Reference
100 MHz to <2 GHz 1.8
2 GHz to <10 GHz 2.4
10 GHz to <12 GHz 2.6
12 GHz to <20 GHz 2.8
20 GHz to 26.5 GHz 3.0
