Adapter test procedure
System calibration
Figure 1-4 System calibration setup
Table 1-3 Equipment list
Instrument Critical specifications Recommended model Manufacturer
Performance network analyzer
(PNA)
10 MHz to 50 GHz E8362B/C, E8363B/C,
N5225A, or similar
Keysight Technologies, Inc.
Adapters 2.4 mm (f), Type-N (f) 11903B Keysight Technologies, Inc.
Adapters 2.4 mm (f), 3.5 mm (m) 11901D Keysight Technologies, Inc.
Mechanical calibration kit Type-N, 50 Ω 85054B Keysight Technologies, Inc.
Mechanical calibration kit 3.5 mm, 50 Ω 85052B Keysight Technologies, Inc.
Mechanical calibration kit 2.4 mm, 50 Ω 85056A Keysight Technologies, Inc.
11500E cable assembly,
3.5 mm (m) to 3.5 mm (m)
3.5 mm (m) to 3.5 mm (m),
DC to 26.5 GHz
11500E Keysight Technologies, Inc.
Table 1-4 Typical specifications
Frequency S-Parameter 08485-60005 08487-60001
50 MHz
S11 and S22 −58 dB −53 dB
S12 and S21
−0.00665 dB (log mag)
0.999235 dB (lin mag)
<0.1%
−0.006908dB (log mag)
0.999205 dB (lin mag)
<0.1%
PNA
Open, Short, Load, Sliding load
Port 1
PNA
Open, Short, Load, Sliding load
Port 2
