Keysight Technologies InfiniiVision 1000 X-Series Service Guide

40 1000 X-Series Oscilloscopes Service Guide
2 Testing Performance
Internal Trigger Sensitivity
Generator Setting Test Limits, greater of Channel 1 Channel 2
100 MHz models: 10 MHz 0.6 div or 2.5 mV ________ ________
Max BW (100 MHz) 1.2 div or 5 mV ________ ________
70 MHz models: 10 MHz 0.6 div or 2.5 mV ________ ________
Max BW (70 MHz) 0.9 div or 3.8 mV ________ ________
50 MHz models: 10 MHz 0.6 div or 2.5 mV ________ ________
Max BW (50 MHz) 0.9 div or 3.8 mV ________ ________
External Trigger Sensitivity
Generator Setting Test Limits Ext Trig In
100 MHz models,
8Vrange:
10 MHz 250 mV ________
Max BW (100 MHz) 500 mV ________
100 MHz models,
1.6 V range:
10 MHz 50 mV ________
Max BW (100 MHz) 100 mV ________
70 MHz models,
8Vrange:
10 MHz 250 mV ________
Max BW (70 MHz) 500 mV ________
70 MHz models,
1.6 V range:
10 MHz 50 mV ________
Max BW (70 MHz) 100 mV ________
50 MHz models,
8Vrange:
10 MHz 250 mV ________
Max BW (50 MHz) 500 mV ________
* Where applicable
